Keithley 2110 5.5 USB Digit Multimeter with Dual Display 2110-100 Tektronix

Product Description

2110 5½-Digit Dual-Display Digital Multimeter Product Description The 2110 5½-Digit Dual-Display Digital Multimeter combines a compelling price with a comprehensive set of capabilities, superior measurement accuracy, and high speed for a broad range of applications. It features 15 measurement functions and 7 math functions and has dual-line display capability, which allows it to display two different measurements concurrently. The 2110 is an unbeatable value for production, R&D, and test engineers, scientists, and students making a wide variety of measurements in portable, bench, and system applications.
Key Features
•High accuracy, high speed for general purpose measurements
• 15 measurement functions, including capacitance and thermocouple measurements
• Dual-line display allows concurrent measurements
• TMC-compliant USB 2.0 interface for use with SCPI test commands
• Includes PC software utilities for graphing and data sharing in both Microsoft® Word and Excel
• Rugged construction for durability in bench/portable applications
• Includes all accessories, such as start-up software, USB cable, power cable, and safety test leads
• CE compliant and listed
• Three year warranty

Title Type Number Release Date

Digital Multimeters (DMM) Selector Guide Complete guide to selecting Keithley digital multimeters (DMMs) including features, benefits, measurement capabilities, and comparison of models.	Product Selector Guide	1KW-61350-3	16 May 2023
2110 5-1/2-Digit Dual-Display Digital Multimeter	Datasheet	1KW-73983-1	09 Mar 2023
KickStart Instrument Control Software Version 2.10.1 (Windows 11, 10, 8, 7 compatible) Users that originally purchased the KICKSTARTFL-BASE license will need to purchase the maintenance license KICKSTARTFL-SUITE-UP in order to use KickStart v2.7.0 and later versions.KickStart Software for the PC enables quick test setup and data visual …	Application	KICKSTART-2.10.1	07 Feb 2023
KickStart Instrument Control Software Datasheet KickStart Software simplifies what you need to know about your instrument so that in just minutes you can take the instrument out of the box and get real data on your device. KickStart Software enables quick test setup and data visualization when us …	Datasheet	1KW-60965-11	12 Dec 2022
KickStart Instrument Control Software Version 2.9.0 (Windows 11, 10, 8, 7 compatible) "KickStart Software for the PC enables quick test setup and data visualization when using one or more instruments.Key Features• Save time by automating data collection of millions of readings.• Set up a multi-instrument test with the ability to indep …	Application	KICKSTART-2.9.0	10 Jul 2022
Using the Dual Measurement Functionality and Dual Measurement Display on the Model 2110	Application Note		28 Jan 2022
Overview of Two-Wire and Four-Wire (Kelvin) Resistance Measurements	Application Note		28 Jan 2022
Making Temperature Measurements with the Model 2110 Many Keithley electrometers, switch/multimeter systems, data acquisition systems, and digital multimeters include temperature measurement capabilities, making them quite useful in a variety of applications in which temperature measurements are neede …	Application Note		28 Jan 2022
Achieving High Reading Rates Using the Data Buffer with the Model 2110	Application Note		28 Jan 2022
Coventry University Case Study This case study takes a look at an advanced, state-of-the-art electrical and electronic engineering laboratory at Coventry University where first and second year students are performing an extensive range of practical electronics and physics experime …

The 2110 is operational and intuitive to use right out of the box. The functions on the front panel are user friendly and easy to read. Its KITool and KI-Link software allow users to quickly control the instrument over USB, record measurements, and display time-series plots of the data. Its LabView® and IVI drivers give more-advanced customers even more control over the instrument. The TMC-compliant USB remote interface allows easy re-use of existing SCPI programs.
Detailed Photos
