Vmc855 Vertical Machining Center Automobile Gearbox Precision Machining CNC Milling Machine

Product Description

Product Description
The 4 axis VMC-850 is a high performance CNC vertical machining center developed and manufactured by our Wayne company. The machine has the characteristics of high rigidity, high speed and high precision and has more advantages on operation and capabilities compared with similar products. All castings of the machine have been secondary tempered to provide excellent rigidity and stability for the whole machine. This machine applied with high rigid C design on structure, it also has been done with reinforcement on machine ribs.All the contact faces have been scraped manually, which guarantees the durability of accuracy. X/Y axes apply with two types of rolling guide way: ball bearing and roller guide way, which is optional that customer can choose base on customer's needs. Z axis applies roller guide way, which enables the machine to be with high rigidity, low noise, and small friction. The machine equips with an air tank, and the water can be drained out manually. Spindle is connected directly, and the highest speed can reach 10000RPM, which make this machie as a good choice for machining some complex parts with high efficiency.

Main Features
Mitsubishi M80 control system High speed and precision spindle Excellent chip flushing system Excellent structure design High rigidity of the whole machine Excellent worktable size: 500mm*1000mm Excellent load capability of worktable: 200kg

ITEM	MODELS	VMC850
WORKTABLE (WIDTH*LENGTH)	mm	500x1000
DISTANCE BETWEEN T SLOTS	mm	5-18x100
MAX LOAD BEARING OF WORKTABLE	kg	600
X/Y/Z AXIS TRAVEL	mm	800/500/500
DISTANCE FROM SPINDLE NOSE TOWORKBENCH	mm	110-810/110-610
SPINDLE HOLE TAPER	-	BT40
SPINDLE SPEED RANGE	r/min	12000
SPINDLE MOTOR POWER	kW	7.5
X/Y/Z RAPID FEED SPEED	m/min	36x36x36
MAX CUTTING FEED SPEED	mm/min	12000
TOOLS MAGAZINE CAPACITY	pcs	24
X/Y/Z POSITION ACCURACY	mm	0.005
X/Y/Z RE-POSITION ACCURACY	mm	0.003
MACHINE DIMENSION	mm	2495x1970x2360
MACHINE WEIGHT	kg	5000

Standard Configuration for VMC Series 1. Full Cover shield
2. Self-lubrication system
3. Working lights
4. Warning lights
5. Working condition warning lights
6. Self-powered electrical shutoff system
7. Clean air gun/ Water Tank / Transformer
8. Spindleair curtain and dust control system
9.10000 RPM spindle
10.Worktable cleaning water gun
Optional Configuration for VMC Series 1. 24 disc manipulator tool magazine
2.Crawler chips remover
3. NCrotary table (4 Axis)
4. CTS
5. Tooldetection system
6,. AJO
7. 12000 & 15000 RPM Direct connection spindle
8. Oil mist purifier
Detailed Photos

Packaging & Shipping
Company Profile
Liaocheng Wayne New Materials Co., Ltd. stands proudly at the pinnacle of CNC Router and Laser Engraving & Cutting technology. Nestled in the vibrant and innovative hub of Liaocheng city, Shandong, our extensive and diverse product line showcases an impressive array of state-of-the-art machinery. This includes Large-scale ATC Woodworking Router Machines that redefine efficiency, advanced 5-axis CNC Router Machines offering unparalleled precision, reliable CNC Advertising Router Machines for seamless branding solutions, precise CNC Marble Engraving Machines for artistic stonework, efficient CNC Plasma Cutting Machines for industrial applications, and cutting-edge CNC Metal Mold Machines. We also offer versatile CNC Lathe Machines, high-precision Swiss Type Lathe Machines, powerful Fiber Laser Cutting Machines, versatile CO2 Laser Cutting & Engraving Machines, state-of-the-art Laser Marking Machines, and highly effective Laser Welding Machines, among others. By harnessing cutting-edge technology and maintaining unwavering quality standards, we are dedicated to building the global brand 'Wayne.' Our superior craftsmanship has propelled our products to reach over 100 countries, including key markets like the United States, Germany, Indonesia, Canada, Australia, Russia, and extensively across Southeast Asia. This remarkable global presence solidifies our position as a true international leader in our field.
Our core mission is to provide unparalleled service excellence to our esteemed customers. Whether you require off-the-shelf solutions or custom configurations, we excel in delivering precisely tailored solutions that meet your unique needs. Each component of our state-of-the-art machines is meticulously sourced from world-renowned suppliers and pioneers in machine control, ensuring not only exceptional performance but also unmatched reliability. Our machines seamlessly integrate into a variety of industries and artistic endeavors, such as woodwork, intricate metal and stone work, aluminum fabrication, boat building, shop fitting, and precision mold making. Supported by a dedicated and highly skilled after-sales service department, an adept sales team, and stringent quality assurance protocols, you can purchase from us with absolute confidence. We warmly invite customers and potential business partners worldwide to join us in cooperative ventures, paving the way for mutual success. By offering the best service, impeccable quality, and competitive prices, Wayne stands as your ultimate choice. We eagerly look forward to collaborating with you to generate greater value. Reach out to us with your requirements, and let's engage in a fruitful conversation. We patiently await your contact, ready to embark on a promising journey together.
Certifications

FAQ
1. Is it all right to make customer's own brand name? A: yes. we are available with OEM

2. Are you a manufactuer or trading company?
A:We are the manufacturer with Laser machine and CNC lathe machine

3. Can you do the design for us?
A: yes. if you want a different control system design or higher column , we are available.

4 . What is your terms of delivery?
A: FOB Qingdao.

5. What's your payment term?
A: T/T OR L/C at sight.
If you want to learn more latest catalog with price list or question ,please contact with me !
