GB ISO ASTM JIS DIN Universal Testing Machine 10/20/50/100kN with High Accuracy Load Cells

Product Description

Product Description
Product DescriptionAT442 Series Universal Testing Machine (original model HY4210) is suitable for tensile, compression, bending, shearing, peeling, tearing and other mechanics performance tests of plastics, rubber, textile, geosynthetics, non-metallic and composite materials. It completely conforms to GB, ISO, ASTM, JIS, DIN and other test standards.StandardItemStandard DescriptionPlasticsIS0 527-1993, ISO 604-2002, ISO 178-2004, ISO 1209-1-2007, ISO 1209-2-2007,ASTM D 638-2008 etc.RubbersISO 37, ISO 34, ISO 5893, ASTM D 2707 etc.TextileASTM D 434, 2261, 3936, 4533, 4964, 5034, 5035, 5735ISO 2062, 5082, 9073.4, 10321, 4606，13934-1, 13934-2, 13937-2, 13937-3, 13937-4, 13935-1, 13935-2 etc.Note: For more standards, please contact usSpecificationModelAT442-10AT442-20AT442-50AT442-100Max. load10kN20kN50kN100kNLoad cell grade0.3Measuring range0.2% ~ 100% F.SLoad resolution＜±0.5%Test travel range0 ~ 900mm0 ~ 700mm0 ~ 500mmTest width400mm ution NESpeed range0.001 - 500mm/minDisplacement resolution1μmDeformation range0.2 ~ 100% F.SLarge deformation measuring range5 ~ 800mmLarge deformation resolution0.0125mmPower supply220 V±15% 50Hz, 1kwOutputColor printerDimension (mm)700*470*1850750*480*19201160*515 *21501070*600*2500Weight240kg260kg280kg320kgDetails & Features★ The high stiffness frame incorporates a crosshead guidance system to prevent side loading of the test sample★ Imported Servo motor and control system, low noisy and high accuracy★ Imported high accuracy interchangeable load cells (SUNCELLS, USA) (0.5% of reading)，having advantages of automatic recognition of the measuring range , controlling parameters and its attribut★ Extensometer, inner diameter measurement system and ring stiffness software is available as options★ Incorporating world proven 32 bit technology for highly accurate load measurement and rapid date acquisition★ Control system platform is based on TI’s DSP control chip, adopt USB connection port★ Import reducer and ball screw lead support system and A/D converter to provide accurately positioning★ Professional software have real time display of on-going testing with data, curve, graphic, and table by personal computer★ The design meets CE requirements for safety.★ Three Closed-loop control system for stress, strain, displacement, high accuracy and more stable★ An extensive built-in library of test methods covering ASTM, ISO, DIN, EN and other test standards★ Test automation and batch testing, 600 test results available★ Varieties of grips are provided on customers’ requirementsOur CompanyHistorySince 1982 with more than 20 years’ experienceWarrantyTwo Year Warranty for whole productTrainingVideo and user manual for trainingOnsite serviceInstallation and training service is availableTesting serviceFree sample testing before order is availableLead time15 working days lead time for most productPacking & DeliveryPackagingPackaging Details1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. PaymentPayment TermT/TEXW30% T/T in advance, paid the balance before shipmentFOBCFR(C&F)30% T/T in advance, paid the balance against copy of B/LCIFL/CL/C amount above 50,000 usd, we can accept L/C at sightWest UnionAmount lower than 5000usdWest UnionDelivery Time7~10days after receiving payment for one containerContacting Us
