New Design Large Diameter Tube Shredding Machine for Pipe Recycling

Product Description

New Design Large Diameter Tube Shredding Machine For Pipe Recycling
Pipe Shredding Machine brief introduction:
The DGR Large Diameter Pipe Shredding Machine is specially designed for handling large diameter pipes(up to 1600mm diameter) without any need for precutting. The DGR rotor diameters range from 800mm to 1500mm and the standard hopper can accept lengths up to 6m. The concave ground, aggressive 4-way rotating knives are mounted in the grooves of the profiled rotor with special knife holders. The DGR shredder range can also be used to shred bundles of small diameter pipes and profiles, lumps, stacked wheelie bins, buckets and pallets, etc.
The hydraulically operated ram feeds the material horizontally in the rotor's cutting chamber by load-related controls. The hydraulic system is equipped with high-pressure valves and volumetric flow controls which can be set according to the requirement of the input material.
Extremely robust pedestal bearing housings are mounted outside the machine and separate to the cutting chamber to prevent dust and dirt penetrating into the oversized bearings. This ensures a long service life and minimum service and maintenance.
Power is transmitted from the motor by a drive belt ia an oversized gearbox which is located on the shaft end on one end of the rotor.
A safty switch prevents machine startup when the front panel is open and the machine features emergency stop buttons on the machine body and control panel.
Pictures of Pipe Shredder Machine :
Specification of Pipe Shredding Machine :

Item		Unit	DGR800	DGR1000	DGR1500
Cutting Chamber		mm	3870*700	6700*870	6700*1300
Rotor Speed		mm	800	990	1430
Main Motor Power		rpm	40	36	23
Rotor Knives		kw	2*37	2*45	2*55
Stator Knives		pcs	60	108	204
Hydraulic Ram Power		row	3	4	5
Machine Weight		kw	11	15	15
Effective Working Area		kg	11000	20000	25000
Dimensions	A	mm	7700	11900	12200
	B	mm	1420	1540	1800
	C	mm	5060	8100	8100
	D	mm	3860	6700	6700
	E	mm	1730	1840	2320
	F	mm	2550	2970	3360
	G	mm	2570	2660	3150
	H	mm	975	1070	1070
	I	mm	590	590	590

Layout for pipe shredder machine :

Key features of Pipe Shredding Machine	Alternertive options
-Large diameter flat rotor -Specially designed feeding trough -Machine pocket knife holders -Optional hard facing -Concave ground square knives -Robust ram construction -Universal couplings -Low speed,high torque geared drive -Powerful horizontal hyraulic ram -Bolts in drive shafts -Multiple rotor designs -Two speed hydraulic system -Oil cooling on ram and gearbox -Amp meter control	-Wedge for thin walled products -Gearbox with shrink disc -Rotor cooling -Touch screen PLC -Increased motor drive -Hydraulic drive -Bespoke colour scheme -Turbo hyraulics -Housing wear plates -Metal detector -Horizontal discharge with overband magnet

Cetificates
Packing and Shipping
1. Several layers of plastic wrapping film and cardboard to protect pipe shredding machine from dust and moisture.
2. Plastic packing strap belt to fasten wrapping film and machines, also to fix machines in containers.
3. Wooden case is used as the outside package and spare parts when choosing by LCL, air or international express.
4. Excellent logistic team to guarantee the double shaft shredder to be safely shipped to customers appointed location.
5. If you have any other request for the packaging or loading, we will do our best to meet your demands.
