Pem-3030s Rotary Small Wood Metal CNC Engraving Machine

Product Description

PEM-3030S Rotary Small Wood Metal CNC Engraving Machine
---Applicable Fields:
This small CNC engraving machines are widely used advertising, seals processing, handcrafts, special instruments processing, little moulds processing, etc. And the rotary engraving machine can engrave kinds of metal or nonmetal stuff, such as: iron engraving, iron cutting, copper engraving, copper cutting ,aluminum engraving, aluminum cutting, plastic engraving, plastic cutting ,wood engraving, wood cutting .etc. Due to its numerous features and applications.
The machine can also be called small CNC router,metal CNC router,rotary engraving machine,small CNC engraving machines.
---Product Features:
1) X, Y, Z axis use imported ball bearing guide screws. It's precise and fast. Even the letters of 1mm can be clearly discernible. The small-power machine uses large-power main axis, it's an ideal product for manufacturing labels, construction models and moulds in batches.
2) High speed calculation It uses DSP64 contouring control system and FPGA technology which can continually and smoothly run the three axes with high speed. It has the ability of calculation of 5000 vector/s.
3) Steady data transmission .The data transmission uses the technology of ISA/IP DNC/IP straight association, which can associate the machine without interruption, and it has no limitation of the amount of the document.
4) Double-nut guide screw .It uses Germany-imported high-precision ball bearing guide screw which can eliminate cracks automatically. Coordinated with the imported shaft coupling, it can realize precise control. It uses straight line guide rail (cylinder or square), which can ensure the working life.
5) Large internal memory capacity of 32M is able to store 30 processing files simultaneously and open and process any of them.
6) Connection with the computer via USB interface enables data to be transmitted in a second, supports hot plug and play, no driver installation required(Window98/NT/2000/XP)
Technical Parameter:Optional items for woodworking:
* DSP Remote Controller (for offline working)
* Dust Collecting System for wood working
* Vacuum Absorbing Table for wood working
---Technical data:

Model	PEM-3030S
Power stroke of X,Y,Z axis	300×300×80mm
Size of working table	520×540mm
Power of main axle	1.5KW
Running location precision of X,Y,Z axis	±0.03mm
Repeating location precision of X,Y,Z axis	±0.01mm
Power stroke of Z axis	120mm
Working style	Stepping motor (Option :Servo Motor)
Spindle speed of frequency conversion main axis	6000-24000rpm/min
Working voltage	AC220V/50HZ
Engraving order	G Code
Optional main axis and Cartridge	φ3.175.φ6
XY Running sensitivity	0.02mm
Optional Item	DSP Remote Controller(for offline working)
	Acrylic Polishing Machine

Except for 300*300mm, we also manfuacture other working area cnc routers, such as 600*900mm, 1200*1200mm. Any interest, feel free let me know.
Before making best quotes for you, could you answer following questions:
* What's your material?(wood, acrylic, plastic, stone, metal etc)
* What's your material working area?
* Your material thickness?
* Your country port for checking shipping.
* If the price confirmed, when will you place order?
* If possible, could you add my skype or whatsapp?
Videos, pictures, samples, PDF are all available!
Perfect Laser Co., Ltd. (China)
Nicole / Sales Department
Add: HengRuichuangzhi Technology Park, No.13 YangQiaohu Road, Jiangxia District, Optical Village, Wuhan, Hubei, China(430200).
Tel: 0086-27-86791986 MP: 0086-13659886768
