Js Series 2000 Litres Double Spiral Twin Shaft Concrete Mixer Js2000
| US$18,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
JS500-3000 Concrete Mixer
Type
Concrete Mixer
Shotcrete Type
Wet
Machining Process
Hydraulic
Structure
Rotor Type
Productivity
120m²/h
Feeding Height
3800mm
Vibrating Amplitude
2.6mm
Certification
ISO9001: 2000, CE
Condition
New
Color
Orange
Discharge Way
Hydraulic
Mixing Power
37kw
Reclaiming Capacity
2000L
Mixing Star* Mixing Blade (Qty)
2*4
Transport Package
Nude
Specification
standard size
Trademark
XINTU
Origin
China
HS Code
847431
Packaging & Delivery
Package Size
100.00cm * 100.00cm * 100.00cm
Package Gross Weight
8000.000kg
Product Description
Brief Introduction of Twin Shaft Concrete Mixer:This JS series twin shaft concrete mixer is compulsory type with main components of feeding system(skip hopper), mixing bowl, discharging system, water supply system and electrical system. It is widely used for small or medium scale concrete batching plant to produce commodity concrete.
Features & Benefits of Twin Shaft Concrete Mixer: 1.The high hardness Mn-steel makes the liner and blade have long working time.
2.With the new designed mixing system, it can work more steady and efficiency.
3. Easy for operating & maintaining, saving more cost.
4. Discharge height can us special designed.
parameters of bucket type twin shaft Concrete Mixer:
| Model | JS1000 | JS1500 | JS2000 | JS3000 | JS4000 | |
| Discharging capacity | 1000L | 1500L | 2000L | 3000L | 4000L | |
| Charging capacity | 1600L | 2250L | 3000L | 4500L | 6000L | |
| Productivity | ≥60m³/h | ≥90m³/h | ≥120m³/h | ≥180m³/h | ≥240m³/h | |
| Maximum size of Aggregate (mm) | <60/80 | <40/60 | <80/100 | <80/100 | <80/100 | |
| Mixing blade | Speed of mixing drum | 32r/min | 30r/min | 25r/min | 22r/min | 20r/min |
| Quantity | 2×7 | 2×8 | 2×8 | 2×9 | 2x10 | |
| Mixing motor | Model | Y180M-4 | Y180-4 | Y200L-4 | Y225S-43 | Y250M-4 |
| Power | 2X18.5kw | 2X30kw | 2X37kw | 2X55kw | 2X75 | |
| Total Weight | kg | 5200 | 5800 | 7500 | 9200 | 12200 |
This efficient machine is widely applied in all kinds of large, middle, and prefabricated concrete plants, highways, bridge project, water conservancy, wharf, etc. It can work together with the tilting cart.
