API Carbon Steel Wcb Flanged Rising Stem Gate Valve
| US$8.00 | 50 Pieces (MOQ) |
Basic Info.
Model NO.
LN-Z1T
Connection Form
Thread
Pressure
Ordinary Pressure
Actuator
Manual
Seal Surface
Wedge Gate Valve
Thread Position of Valve Rod
Inside Gate Valve
Usage
Regulation
Standard
DIN
Application
Industrial Usage, Water Industrial Usage, Household Usage
Transport Package
Small Box-Cartons-Plywood Case
Specification
1/2"-4"
Trademark
LEINA
Origin
China
HS Code
8481804090
Production Capacity
5000/Month
Product Description
Gate valve 200WOGFeatures
Stainless Steel one piece Seat
Various Thread Standards Available
Using dewaxing precision casting
Product standard
Design: ASME B16.34
Wall Thickness: ASME B16.34
Pipe Thread: ASME B1.20.1, BS21, DIN 2999/259, ISO 228/1, JIS B 0203, ISO 7/1
Inspection & Testing: MSS SP-110, EN 1226
| No. | Parts name | Material | |
| ANSI/JIS/DIN | ANSI/JIS/DIN | ||
| 1 | Body | A351-CF8M/SCS14A/1.4408 | A351-CF8/SCS13A/1.4308 |
| 2 | Disc | A351-CF8M/SCS14A/1.4408 | A351-CF8/SCS13A/1.4308 |
| 3 | Stem | SUS316 | |
| 4 | Cap | A351-CF8M/SCS14A/1.4408 | A351-CF8/SCS13A/1.4308 |
| 5 | Cap gasket | PTFE/RPTFE/PPL | |
| 6 | Circlip for shaft | SUS304 | |
| 7 | The Gasket | SUS304 | |
| 8 | Stem packing | PTFE/RPTFE/PPL | |
| 9 | Washer | SUS304 | |
| 10 | Packing nut gland | A351-CF8M/SCS14A/1.4408 | A351-CF8/SCS13A/1.4308 |
| 11 | Wheel Handle | Aluminum | |
| 12 | Elastic gasket | SUS304 | |
| 13 | Hexagon nut | A194-8 | |
| Size | L | H | E |
| 1/2" | 55 | 93 | 70 |
| 3/4" | 60 | 105 | 70 |
| 1" | 65 | 115 | 80 |
| 1-1/4" | 75 | 130 | 80 |
| 1-1/2" | 85 | 145 | 100 |
| 2" | 95 | 170 | 100 |
| 2-1/2" | 106 | 200 | 125 |
| 3" | 116 | 218 | 125 |
