Suntech Water Tank Wet Steel Wire Drawing Machine for Binding Wire

Product Description

Super Fine Water Tanke Wire Drawing Machine
Product Description

I. Features of Machine: 1.1 Automatic tension control by dual-inverter.
1.2 Moyable reel traversing unit.
1.3 Zero-slip pilot design,high productivity,high quality finished wire.
1.4 Widely used imported advanced parets and components, ensure high quality finished products
II. Applications:
Water Tank Wire Drawing Machine are suitable for the high & low carbon steel wire below size of 2.8mm, with inverter control system to assure high speed & stable operation.
Low Carbon steel wire product used in mesh net, steel fiber, binding wire, nail & staple making, construction, agriculture & furniture field, etc. And other steel wire product used in prestressing wire, PC wire, spring, steel rope wire, tyre cord & Bead wire for tyre, etc.
III.Working flows and automation:
Wire pay off →Water Tank Wire Drawing Machine→Automatic take-up
IV. For more complete projects, please visit:
PC strand production line:
https://suntechmachinery.en.made-in-china.com/product/VGzUcEJyVnkM/China-PC-Wire-Strander-Stranding-and-Heat-Treatment-Line.html
LRPC wire production line:
https://suntechmachinery.en.made-in-china.com/product/vsVQHLqGZycp/China-Suntech-Prestressed-PC-Low-Relaxation-Lrpc-Indenting-Steel-Wire-Production-Line-Machines.html
Railway Pile Concrete PC Bar production line:
https://suntechmachinery.en.made-in-china.com/product/bCVENrFopjkX/China-Prestressed-Concrete-PC-Bar-Induction-Heating-Machine-Production-Line.html
Product Parameters
II. Main Technical Parameters:

Item	water tank wire drawing machine
Applications	low carbon steel wires, for micro woven mesh, making wire mesh, fence, steel fiber, binding wires
Power control	Dual frenquency inverter
Input wire diameter	0.08-0.2mm
Output wire diameter	0.025-0.06mm
Dies number	24 dies
Max. running speed	2000meters/min
Traversing method	Synchronous motor and belt

III. Details of machine for reference:
