Pulley Driven Wire Drawing Machine

Product Description

Machine Introduction
Production process :
Product Description
Low Carbon Steel Wire Drawing Machine
Introducing the Low Carbon Steel Wire Drawing Machine from Hebei Kaiye Machinery Equipment Co.,Ltd. This high-quality machine is designed to meet all your wire drawing needs efficiently and effectively.
Key Features:
High pay-off frame for smooth operation
Mechanical derusting for clean wire production
Straight line wire drawing machine for precision
Tension device for consistent wire drawing
Wire take-up machine for easy handling
Specifications:
The frame of the machine is welded using buttress plate, bent steel, and section steel to ensure rigidity and safety. The drive is powered by an AC frequency motor through high-frequency joint narrow V-belts. The capstan structure is made of ZG45 steel casting blank body with a hardened layer for long service life. Capstan cooling is achieved through a water jacket system for efficient cooling.
Die Box:
The die box is a welded structure with two cavities. It includes a guide roller to ensure straight wire entry into the drawing die. The tuning roller allows for fine-tuning of the speed for optimal performance.
Upgrade your wire drawing process with the Low Carbon Steel Wire Drawing Machine from Hebei Kaiye Machinery Equipment Co.,Ltd. Order yours today!
Machine Specification

Items	Unit	LZ10/800	LZ9/700	LZ10/560	LZ10/400
Reel diameter	mm	800	700	560	400
Draw passage	time	10	9	10	10
Incoming dia	mm	Φ10-8	Φ8-6.5	Φ6.5-5.5	Φ14-8
Outgoing dia	mm	Φ4-3	Φ3-2.5	Φ2-1.8	Φ1-0.8
Wire darwing line	m/min	360	480	720	840
Incoming strength	Mpa	≤1300	≤1300	≤1300	≤1300
Total compressibility	%	84-85.94	85.94-85.21	90.53-89.29	87.24-84
Average compressibility	%	18.42-19.58	19.58-19.13	21.00-20.02	18.61-16.74
Single motor power	Kw	90-55	75-55	37-22	15-7.5

Machine Features

Wire Pay off system. Pay off system is usually according to the type in the picture, pneumatic lifting pulley, convenient wire threading.we can also produce hydraulic wire pay off systems.

Derusting machine. The derusting machine uses high-speed operation to twist the wire rod at different angles to remove the rust on the surface.

Drawing drum. The drum of drawing machine adopts narrow slot water cooling, which has good cooling effect. And it is not easy to enter the dust.The drum is sprayed with tungsten carbide coating to prolong the service life.

Packaging & Shipping

Package. The main machinery is packed with plastic film and fixed in the container with steel wire. Small mechanical parts are packed in wooden cases.

Shipment. We can book containers for customers according to the mechanical size. If we need LCL, we can arrange to pack and send them to the designated place.

Certifications
Company Information
Hebei Kaiye Machinery Equipment Co.,Ltd.
Factory History
Hebei Kaiye Machinery Equipment Co., Ltd. was established in 2002. We specialize in the research, design, manufacturing, and sales of CNC steel wire processing equipment. Our products offer comprehensive solutions for CNC steel wire processing needs. They are extensively utilized in various sectors including railway, highway, bridge, tunnel, real estate, and animal husbandry, as well as in steel processing and distribution centers.
Wire Mesh Machinery by Hebei Kaiye Machinery Equipment Co.,Ltd.
Factory Workshop
Hebei Kaiye Machinery Equipment Co.,Ltd. operates its own wire mesh machinery and pilot plants equipped with advanced technology and production equipment. Our product range includes:
Straight Line Wire Drawing Machine
Pulley Wire Drawing Machine
Wet Drawing Machine
Copper Wire Drawing Machine
Stainless Steel Wire Drawing Machine
Galvanized Wire Production Line
Wire Winding Machine
Other Wire Drawing Supporting Machinery
Our machinery is designed to meet the highest standards of quality and efficiency, ensuring optimal performance in wire drawing processes.
Hebei Kaiye Machinery Equipment Co.,Ltd.
Factory R&D Team
Hebei Kaiye Machinery Equipment Co.,Ltd. boasts a robust R&D team with extensive experience. Each engineer has an average working experience of over 8 years. Our technology aligns with the most advanced international standards, enabling us to craft tailored solutions based on customer requirements.
Customer and Market
Welcome to Hebei Kaiye Machinery Equipment Co.,Ltd.! Our machinery and equipment are highly sought after worldwide, with a strong presence in over 100 countries and regions including Romania, Lithuania, Turkey, and many more. With over a decade of experience, we have become a leading enterprise in the industry, prioritizing customer satisfaction and cutting-edge technology. Our commitment to industrial development and innovation sets us apart as we strive to create the world's premier steel processing equipment.
FAQ
