Wxc80 Automatic Metal Steel Round Bar Pipe Peeling Machine

Wxc80 Automatic Metal Steel Round Bar Pipe Peeling Machine

US$160,000.00
1 Set
US$150,000.00
2+ Sets

Basic Info.

Model NO.
WXC80
Processing Range
Dia. 20-80mm
Length Range
Not Less Than 2500mm
Accuracy
H10
Transport Package
Seaworthy Package
Trademark
HAIGE
Origin
Yantai, China

Product Description

Automatic Metal Round Bar Peeling Machine

Company Information
Product Description Series WXC Peeling Lathe Machine is a high-efficiency lathe which is specialized in processing the surface of steel round bar and steel wire rod, for example, straightening, peeling, cutting and polishing, etc.
Not only quickly remove surface hardened layer, cracks and other defects, but also can get high precision.
During processing, the bar doesn't rotate itself. The cutting tools rotates at high speed to peel the surface of the bar. At the same time, after peeled , the bar keeps walking forward.
Shapes of Workpiece are requested long steel round bar and steel wire rod.
Main Technical Parameters (just for reference)
Specification WXC80C (semi-automatic type)
Black bar required Diameter Range (mm) Φ20~Φ80
Length Range(mm) 2500~6000
Yield Strength σb (Mpa) ≤1100
Surface Hardness ≤HB320
Straightness ≤1.5‰
Diameter Tolerance according to GB 702-2004 second group
Roundness(mm) ≤50% of diameter tolerance
Surface Roughness (Ra) ≤25~50μm
After peeling Diameter Range (mm) Φ19~Φ77.5
Diameter Cutting Depth (mm) 1.0~2.5 (minimum cutting depth depends on the ovality of the raw material)
Diameter Tolerance h10-h9
Surface Roughness (Ra) 6.3-3.2μm
Feeding Speed (m/min) stepless speed 1.0~10.0(it should be slowed down if the bar is continuous chips, with high strength, high hardness, larger diameter or smaller diameter, larger or smaller cutting depth)
Cutter Head Rotational Speed(rpm) 430~1200 (stepless speed)
Main Motor (kw) 75
Voltage 380V
Frequency 50HZ
Total Capacity(kw) 95(approximately)
Dimension of main machine (L x W x H) 5.1m × 3.3m × 2.2m
Dimension (loader&unloader included) (L x W x H) 32.5m x 6.0m x 2.2m
Weight (T) - Main Machine 8.5 (for reference)
Compressed air (prepared by user) 0.5~0.8MPa,1.8m³/min, more than 0.8 m³ air storage tank with two stage oil water separator and Compressed Air Refrigeration Drier


Packing Details
More details, please contact me
