8 Ports 10/100/1000Mbps Managed Poe Switch with 2 Gigabit SFP

Product Description

8 Ports 10/100/1000Mbps Managed PoE Switch with 2 Gigabit SFP Product Description This 8-port WEB Smart Industrial gigabit PoE Switch provides a comprehensive security protection system, perfect QoS policy & flexible VLAN function, and simple management & maintenance. It welly meets the access and networking requirements of enterprises, communities, hotels, office networks, and campus networks.
Key Features :
1. Fully Layer2 Web smart management with Console port
2. Fully IEEE802.3af/at standard compliant.
3. Support 250m PoE distance transmission.
4. Plug & Play. No configuration.
5. 6KV Surge protection
6. Ports: 8 Ports 10/100/1000Mbps RJ45 with 2 Gigabit SFP
Detailed Photos
Efficient Secure Management Interface
For efficient management, the managed gigabit PoE Switch is equipped with Web and SNMP management interfaces. It offers easy-to-use/configure/install/troubleshoot in video surveillance, wireless access, and other SMBs and enterprise applications.
Solution for IPv6 Networking
The POE switch is the best choice for IP surveillance, VoIP and wireless service providers to deploy the IPv6 network.
Robust Layer 2 Features
The WEB Smart Industrial gigabit PoE Switch can be programmed for advanced switch management functions, such as dynamic port link aggregation, Q-in-Q VLAN, Multiple Spanning Tree Protocol (MSTP), Layer 2/4 QoS, bandwidth control and IGMP/MLD snooping.
Redundant Ring, Fast Recovery for Critical Network Applications
The smart network switch supports redundant ring technology, it incorporates advanced Spanning Tree Protocol (802.1s MSTP), and a redundant power input system into the industrial automation network. In a simple Ring network, the recovery time of data link can be as fast as 20ms.
Two Gigabit SFP Uplink Ports
The additional two mini-GBIC SFP slots built-in the switch support dual speed, 1000BASE-SX/LX SFP fiber-optic modules. By using the SFP transceiver, the transmission distance can be extended from 550 meters to 2km (multi-mode fiber) and to 20/40/60/100/120 kilometers (single-mode fiber or WDM fiber).
Smart PoE Power Supply
The PoE Switch Series provides maximum power budget of 120W for all PoE ports and 30W for every single PoE port respectively.
PoE AI Watchdog
It offers 24/7 real-time monitoring PD(power device) status. When a PD crashes, the switch will automatically detect the failure an d reboot the crashed the unworking camera.
Surge Protection
This PoE switch is based on the IEC61643-21:2000 standard,Reaching 6KV surge protection.
Product Parameters
