Horizontal Wind Turbine 1MW 2MW 3MW Wind Turbine Best Wind Power Generation System

Product Description

Horizontal Axis Wind Turbine HF - 3.3MW
Model	HF-3.3MW	Blade Material	3 pcs
Rated power	3300KW	Rated Voltage	1140V/Customized
Wind Wheel Diameter	164m	Start-up Wind speed	2.5m/s
Rated wind speed	9.3m/s	Survival wind speed	52.5m/s
Blade Length	80.5m	Height of Tower	90M
Generator shell material	Pressure Cast Iron	Design standard	IEC61400-24
Tower material	S355 free stand tower with painting against decaying
Blade Material	High efficiency FRP material, unidirectional high strength glass fiber
Type of Generator	Permanent magnet synchronous engine
Control System	SCADA Remote monitoring
The Wind Adjustment	Automatic Windward Adjustment
Brake System	3 blade pneumatic brake & Principal axis tong disc brake
Lightning Protection System	Blade tip lightning protection
Working Temperature	-30ºC~50ºC
Degree of Protection	IP54
Safety level	IEC S
Design Life	20 Years

Enjoy convenient & efficient clean energy!
1. Start at low wind speed, maximize the utilization of
wind energy, and operate stably at super wind speed;
2. The wind farm for unit construction is easy to install,
with small floor area and small working space radius;
3. The unit is small, light and convenient for transportation;
4. Superior power quality, easy to control by the energy
center, and good affinity for micro grid projects;
5. The total cost of a single unit is low, which is convenient
for the company and individual investment income;
6. It has the technical characteristics of megawatt wind
turbine such as active yaw, pitch, full power inverter, low
voltage ride through, SCADA, etc.
FAQ
Answer your questions
Q1:Wich model wind generator is suitable for me?
A1: Plese contact with our sales, Cemi will help you choose the most suitable model for you.
Q2:What about the delivery?
A2: If the model of wind turbine you need is in stock, Cemi can delivery wind generator in 10days to 25days after receiving your payment, and Cemi can help you ship all over the world.
Q3:For home use, which one is better?
A3: Normally we sell 5kw & 10kw wind hybrid system for home use.
Q4: Does installtion Easy ?
A4: Very easy, every customer can do it by themselves, Cemi will supply all the components for installtion and detailed installtion manual for your reference, if any questions, pls feel free to contact with our sales maganer and engineer.
Q5: What size of wind turbine or motor do you produce?
A5:Cemi produce from 150W to 300KW wind turbine, can supply parts or whole unit.
Q6: How long is the lifetime of wind generator?
A6: The life time of wind turbine is more than 26 years.
Q7: What can be included for this system?
A7: Full set of wind energy system: wind turbine(wind generator+blades+tower), wind controller, inverter, battery.
