LP141- SPEC |
Type | Item | Description | Remark |
product type | Notebook | |
LCD | Size | 14" | |
Ratio | 1920*1200 16:10 | |
Touch Panel | NA | |
Physical parameter | Front | plastic cement | |
Tilt adjust | 180° | |
Kingston Lock | Support | |
Weight | 1.4kg | |
Packing Size | 314.40*220.00*19.9mm | |
I/O Port | Left | |
DC JACK | 3.5-head standard DC interface | |
USB Type_C | 1*Type-C data only | Optional Full functionality |
HDMI | 1*HDMI 1.4 | |
USB Type_A | 1*USB3.2 Gen1 | |
right | |
headset | 1*Ø3.5mm Combo | |
USB Type_A | 2*USB3.2 Gen1 | |
card reader | TF card reader | |
RJ45 | Optional | |
indicator light | Charging light | Left side of C shell | |
power light | Top left front of C shell | |
keyboard | Backlight | YES | |
layout | US | Optional |
Hardware |
CPU | type | intel Alder Lake I5-1235U/I7-1255U/I3-1315U | Supports 12-13 generation U/P series CPUs |
parameter | 12th generation 10-core, main frequency 1.7G, maximum frequency 4.5G, cache 12M, power consumption 15W | |
GPU | type | Intel® Iris® Xe Graphics eligible | |
Memory | RAM | 16GB,2*LPDDR4 | |
Storage | ROM (eMMC/UFS) | NA | |
SSD | Optional | support64GB/128GB/512GB/1TB/2TB |
Battery | type | Li-polymer Battery | |
Number of battery cells | 3 battery cells,1 strings | |
Voltage&Current | 11.5V/5000mAh | |
capacity | 58Wh | |
Fast charging | Support | |
sensor | G sensor | NA | |
H sensor | Support | |
key | power key | Integrated into keyboard | |
camera | front camera | 2MP,HD 1920*1080 | |
Privacy switch | Support | |
Touchpad | type | Integrated touchpad | |
Multi finger touch control | Support | |
fingerprint | type | Optional | |
AUDIO | speaker | 8Ω 1W *2 | |
Audio processor | ALC269 | |
MIC | DMIC Integrated into the camera | |
security | TPM | FTPM | Optional DTPM |
Confidential chip | NA | |
RTC | RTC | Support | |
other | | |
Connectivity |
WiFi | type | WiFi module wifi5 | Optional wifi 6 |
agreement | WiFi 802.11b/g/n/ac | WiFi 802.11ax |
frequency | 2.4G/5G | |
Bluetooth | type | Integrated module | |
edition | BT4.2 | |
Mobile LAN | 4G LTE | NA | |
Wired network | Gigabit Lan | Support, requires USB adapter | |
Software |
OS | Support types | win10/win11 | |
language | Optional | |
BIOS/EC | UI specifications | General specifications | |
Adapter |
Adapter | input | AC 100~240V | |
output | 19V 3.42A 65W | |
Reliability&Certification |
Reliability | Warranty period | 1 year | |
ESD | Contact:±4KV,air:±8KV | |
Certification | EMI | class B | |
3C | Support Certification based on customer needs |
FAQ |
Q1/Can I take a sample for quality check ? |
Sure,we offer sample for testing quality . And If you want OEM support , we also could offer different specification for selection , you can contact us on line sales team for support.We can make the samples according to your requirements. |
|
Q2/ what's your shipping way? |
We have shipping partners worked with over years, they can offer various service including DHL /UPS/ FEDEX/ ARMEX etc, as well as airway shipping , railway shipping or sea shipment . try to give the best shipping method to your side . And if you would like to select your own shipping agency it also could be Ok to support |
|
Q3/ Can you do OEM service ? |
Yes, OEM and ODM is our main business ,we do a lot of project or tender order in some countries ,You can contact our one line sales team to get personalized service support. |
|
Q4/Can you add logo on the products? |
A4:Yes,we can. Laser print,Silk print for your choose. |
|
Q5.Can you customize package box for us? |
A5:Sure,our factory produces OEM/ODM. |
|
Q6/ How can I do if have problem with products ? |
All products will be checked at least three times before sending in order to make sure everything is qualified . we offer one year warranty for our products . Send us the pictures or video first time,we will send free replacement spare parts for you. |
