Hydraulic Guillotine Cutting Machine 6mm

Hydraulic Guillotine Cutting Machine 6mm

US$10,000.00-15,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
QC11Y-6x3200
Condition
New
Warranty
2 Years
Main Motor
7.5kw
Control System
Estun E21 Nc
Cutting Thickness
6mm
Cutting Length
3200mm
Precision
High Precision
Hydraulic Valve
Germany Rexroth
Back Gauge
0-600mm
Cutting Angle
Adjustable
Transport Package
Nude Packing, Steel Pallet
Specification
3800x1750x2000mm
Trademark
WOKE
Origin
Nantong, Jiangsu, China
HS Code
8462399000
Production Capacity
40PCS/Month

Product Description

COMPANY EXPERIENCE
WOKE MACHINERY EQUIPMENT is focus on supplying good quality metal sheet processing equipment in world market in Americas, Middle East, Southeast Asia......It is in this area more than 10 years of experiences.
Woke Machinery Equipment is certified according to ISO 9001, SGS.
Woke Machinery Equipment is always ready to meet customer requirements competitive prices, short production times and high quality equipment. The company's motto is "Our goal is to offer our customers high quality at an affordable price"
MACHINERY SUPPLY RANGE PERFORMANCE OF SHEARING MACHINE
1.Come with world famous Estun E21s NC control system, stable performance and easy to operate.
2.Steel welded structure, vibration aging treatment to eliminate internal forces, have high strength and good durability.
3.Advanced integrated hydraulic system, easy for maintenance.
4.The shear stroke and cut times can be controlled.
5.Feeding balls on worktable to reduce the hurt of the plates and reduce conflict force.
6.Manual adjusting of blade clearance and adjustment of gap can be showed on an indicating dial.
7.The blade is of 4 cutting edges, that mean you can change the cutting edge if long time use.
8. Front supprt arms with scale and standard protective guard, meet with internationl safety standard.
TECHNICAL PARAMETERS
Model Cutting Thickness Cutting Length Cutting Angle Strength Strokes Main Power
(mm) (mm) (°) (KN/CM) (spm) (kw)
QC11Y-4X1500 4 2000 0.5°~1.5° ≤450 20 5.5
QC11Y-4X2500 4 2500 0.5°~1.5° ≤450 18 5.5
QC11Y-4X3200 4 3200 0.5°~1.5° ≤450 14 7.5
QC11Y-4X4000 4 4000 0.5°~1.5° ≤450 10 7.5
QC11Y-6X6000 6 6000 0.5°~2.0° ≤450 20 11
QC11Y-6X2500 6 2500 0.5°~1.5° ≤450 17 7.5
QC11Y-6X3200 6 3200 0.5°~1.5° ≤450 14 7.5
QC11Y-6X4000 6 4000 0.5°~2.0° ≤450 10 7.5
QC11Y-8X2500 8 2500 0.5°~2° ≤450 14 11
QC11Y-8X3200 8 3200 0.5°~2° ≤450 10 11
QC11Y-8X4000 8 4000 0.5°~2° ≤450 8 11
QC11Y-10X2500 10 2500 0.5°~2° ≤450 12 11
QC11Y-10X3200 10 3200 0.5°~2° ≤450 10 11
QC11Y-10X4000 10 4000 0.5°~2° ≤450 8 11
QC11Y-12X1500 12 1500 0.5°~2° ≤450 14 15
QC11Y-12X2500 12 2500 0.5°~2° ≤450 10 15
QC11Y-12X3200 12 3200 0.5°~2° ≤450 10 22
QC11Y-12X4000 12 4000 0.5°~2° ≤450 7 22
QC11Y-12X6000 12 6000 0.5°~2° ≤450 10 22
QC11Y-16X2500 16 2500 0.5°~2° ≤450 8 22
QC11Y-16X3200 16 3200 0.5°~2° ≤450 7 22
QC11Y-16X4000 16 4000 0.5°~2° ≤450 6 22
QC11Y-16x6000 16 6000 0.5°~2° ≤450 6 37
QC11Y-20X2500 20 2500 0.5°~2° ≤450 6 30
QC11Y-20X3200 20 3200 0.5°~2° ≤450 5 30
QC11Y-20X4000 20 4000 0.5°~2° ≤450 5 30
QC11Y-25X2500 25 2500 0.5°~2° ≤450 5 37
QC11Y-25X3200 25 3200 0.5°~2° ≤450 5 37
QC11Y-30X2500 30 2500 0.5°~2° ≤450 4 45
QC11Y-30X3200 30 3200 0.5°~2° ≤450 4 45
Our Factory Workshop Show
CONTROL SYSTEM OPTIONS
Estun E21s NC, frequency drive or reducer E200PS, servo drive Delem DAC360, CNC Customers witnessed WOKE growth
