Qizhi Membrane Panel Automatic Bending Machine for Boiler Fabrication
| US$40,000.00-80,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
QZ PBM
Condition
New
Certification
ISO 9001:2000, ISO 9001:2008
Automation
Automatic
Suitable for
Alloy, Carbon Steel, Stainless Steel
Type
Pipe and Tube Bending Machine
Suitbale for
Water Wall Membrane Panel Bending
Transport Package
Container
Specification
max. 2500mm
Trademark
QIZHI
Origin
China
HS Code
8462299000
Production Capacity
50sets Per Year
Product Description
Panel bending machineThis machine is a professional equipment for bending membrane wall tube banks in the boiler industry. Its curvature is consistent, which improves product quality, reduces labor intensity for workers, and improves labor productivity.
Specifications:
| Width | Torque | Max. bending force | Power | Type | Bending radius | Angle of bending |
| 1600mm | 170KN.m | Motorized | Horizontal | 200-400mm | 0-135° | |
| 2500mm | 450KN.m | Motorized | Horizontal | 200-400mm | 0-135° | |
| 2500mm | 500KN.m | Hydraulic | Horizontal | 200-400mm | 0-135° | |
| 3000mm | 500KN.m | Hydraulic | Horizontal | 200-400mm | 0-135° | |
| 1600mm | 150T | Hydraulic | Vertical | 200-400mm | 0-135° | |
| 2500mm | 150T | Hydraulic | Vertical | 200-400mm | 0-135° |
QIZHI provides various fabrication machines for boiler fabrication Boiler Fabrication Machines
