Laboratory Roving Machine for Wool Fiber with Touch Screen Control

Product Description

Product Description
Product Description
AT205M Laboratory Roving Machine is part of the mini spinning system. It’s mainly used in university, researching center etc. and it is used to make roving from sliver. And in the same time, insert the twist into the roving and then winding the twisting roving on bobbin.
Specification

Model	AT205M
Spindle number	4
Fiber type	Cotton or wool (alternative)
Twisting range	50-250 twist/m
Drafting range	Approx. 2~50
Fiber length	50 ~ 112 mm or customized
Output capacity	2 ~ 3 kg per hour or customized
Roller diameter	Φ38/32/38mm
Output speed	Approx. 12m/min
Spindle flyer speed	600rpm
Output capacity	2-6kg
Can size	Φ250*550mm
Power	220V/380V, 50/60Hz, 3KW
Dimension	1500*1000*1600mm

Details & Features
★ It adopts touch screen and PLC control.★ Imported frequency converter of high efficiency.
★ Mini type machine, save researching cost and easy to operate and maintain.
★ Can be used for cotton fiber or wool fiber (alternative) with different machine parts.
Our Company
History
Since 1982 with more than 20 years’ experience
Warranty
Two Year Warranty for whole product
Training
Video and user manual for training
Onsite service
Installation and training service is available
Testing service
Free sample testing before order is available
Lead time
15 working days lead time for most product
Packing & Delivery

Packaging
Dimensions	1160x510x1050mm
Weight	Approx. 80kg
Packaging Details	1. The equipment is covered with film is protect it from water vapour during the trip.  2. The box is filled with foam to protect the equipment from impact.  3. Exported wooden box made from plywood, don't need fumigated.

Payment

Payment Term	T/T	EXW	30% T/T in advance, paid the balance before shipment
					FOB
				CFR(C&F)	30% T/T in advance, paid the balance against copy of B/L
				CIF
		L/C	L/C amount above 50,000 usd, we can accept L/C at sight
		West Union	Amount lower than 5000usd
		West Union
Delivery Time	7~10days after receiving payment for one container
