Hybrid Powder Coating Epoxy Polyester Metallic Finish Powder Paint for Aesthetic Appeal

Product Description

Product Description
Product Description
Understanding hybrid technology in powder coatings
Hybrid technology in powder coatings is a unique blend of epoxy and polyester.
We utilize this combination to produce coatings primarily intended for interior use.
The merging of these two materials culminates in a hybrid solution that exhibits enhanced mechanical and chemical resistance compared to standard polyester coatings.
These epoxy-polyester hybrids also offer a superior finish quality and provide adequate corrosion protection.
Still, due to their limited UV resistance, they are not recommended for outdoor applications.
This blend of characteristics makes hybrid technology a well-regarded choice for decorative coatings in indoor settings.
Product Features
Hybrid powder coatings offer numerous benefits, particularly in terms of their application and performance:
- High Quality Finish: These coatings provide a superior finish resulting in a smooth and polished appearance particularly suitable for appliances and furniture.
- Robust Resistance: Hybrids Epoxy-Polyester coatings offer improved color, UV-light and heat stability compared to pure epoxy coatings.
- Corrosion Protection: Hybrid coatings offer commendable protection against corrosion, prolonging the lifespan of the coated objects.
- Versatility: Their flexibility allows for effective coating on a wide array of surfaces, proving them to be a versatile solution.
Application Area
Hybrid powder coatings are generally found in office furniture, metal cabinets, shelving, interior light fixtures, power tools, and automotive underbody/underhood parts. They are primarily intended for interior use.
Installation Instructions

Key points and Tools of How to Apply:

For wood products

1. Use a brush on flat surfaces to cover large areas. 2. Wipe contoured and uneven surfaces with a rag to avoid drips from brushing. 3. Spray hard-to-reach areas with an aerosol can. 4. Sand the wood before applying polyurethane to create a smooth surface. 5. Be sure to wipe away any remaining dust. 6. Wait for each coat of polyurethane to dry before applying the next. 7. Sand the wood between coats.

For Art Craft Products

Surface Preparation: The first step is to prepare the surface of the metal art craft. This involves cleaning the surface to remove any dust, oil, or other contaminants. You can use a sandblaster or a wire brush for this purpose.Powder Coating Gun: A powder coating gun is used to apply the powder to the metal surface. The gun gives the powder a positive charge, which helps it adhere to the grounded metal surface.Powder Coating Booth: A powder coating booth is needed to contain the powder and prevent it from spreading to other areas. The booth should be well-ventilated to ensure that the powder doesn't accumulate in the air.Curing Oven: After the powder is applied, the metal art craft needs to be placed in a curing oven. The heat in the oven causes the powder to melt and form a hard, durable coating.Safety Equipment: Safety equipment such as gloves, safety glasses, and a dust mask should be worn during the powder coating process to protect against potential hazards.Proper Grounding: The metal art craft needs to be properly grounded to ensure that the powder adheres to the surface. This can be achieved by attaching a grounding clamp to the metal.Masking: Areas of the metal art craft that you don't want to be coated should be masked off using high-temperature tape or silicone plugs.Post-Curing: After the powder coating has been cured, it should be allowed to cool before handling. This ensures that the coating has fully hardened and will not be damaged.

Product Parameters

Product Specification

Hybrid powder performance can be summarized as follows: - Enhanced overbake resistance vs. epoxy - Good Faraday Cage penetration (easier to penetrate recesses found in the part to be coated) - Full range of gloss (10-95+) - Ultra smooth, thin films (0.8-1.2 mils) - Economical

Product Testing Data
The formulated coatings were cured and then evaluated via dynamic mechanical analysis (DMA), differential scanning calorimetry (DSC),thermomechanical analysis (TMA), thermogravimetric analysis (TGA), rheological measurements, and general coatings tests.

The State in the Container	Uniform color, without foreign matter, fluffy powder
Screenings (125μm)	Concerted
Appearance	Texture clear, equally distributed, without impurity and big particle
Hardness	Flat Surface ≥Fair, concerted with rough surface
Adhesion	≤ Level 2 (film thickness 60 ±10 μm)
Impact Resistance	≥ 40 cm (film thickness 60 ±10 μm)
Bending Test	≤ 4 mm (film thickness 60 ±10 μm)
Cupping Test	≥ 4 mm (film thickness 60 ±10 μm)
Alkalis Resistance (5% NaOH)	168 Hours no abnormal, concerted with metallic powder
Acids Resistance (3% HCI)	240 Hours no abnormal, concerted with metallic powder
Damp Heat Test	500 Hours no abnormal
Salt Mist Test	500 Hours no abnormal, ≤ 2.0mm corrosion at break line
Accelerated Aging Test	500 Hours, Fade ≤ 2 grades; Loss of gloss ≤ 2 grades;concerted with metallic powder
Heavy Metal	Almost Zero (Test by ROHS Standards)
Soluble Lead/chrome	Almost Zero (Test by ROHS Standards)
