26t Amphibious Excavator with Max. Digging Reach 9.9meters

Product Description

KZX 200-3 Amphibious Excavator Technical Parameter
Max. Digging reach: 9.9meters
2 chains pontoon

Model	KZX200-3
Operating weight	26000kg
Bucket capacity	0.8m3
No .of Chains	2
Performance
Ground pressure	0.13 kg/cm2
Slew speed	13.3rpm
Max. travel speed high .low	3.3/2.3km/h
Gradeability	25°

Model	KZX200-3
A.Length of pontoon	8000mm
B.Overall length	10620mm
C.Cab height	3688mm
D.Counter weight clearance	1900mm
E.Boom transport weight	3748mm
F.Min. ground clearance	1160mm
G.Width of pontoon	1600mm
H.Overall width	5360mm
I.Upper structure width	2710mm
J.Height of pontoon	1700mm

Model	KZX200-3
A.Max.digging reach	9920mm
B.Max.digging depth	5800mm
C.Max.cutting height	10910mm
D.Max.dumping height	8050mm
E.Min.front slew radius	3180mm

Engine
Model	ISUZUAI--4HK1X	Working pressure	32.9Mpa
Type	Turbe-charged with inter-cooled	Slewing motor	Fixed displacement piston motor
Power	110kw/2100rpm	Travel motor	Variable displacement piston motor
Displacement	4.329L	Fuel tank capacity	310l
Pump type	Variable displacement axial piston pump	Hydraulic tank capacity	200L

Maintenance holes: When the machine malfunction, facilitate personnel in maintenance and repair.. Its our company's patent. (option)

After-sales Service
Warranty
Kudat grants our clients a twelve-month-period or 1500-hours warranty for any machine purchased from us. During the warranty period, in case the defect of material or workmanship has occurred with spare parts in normal operation. The defective part will be repaired or replaced free of charge at our discretion.

Spare Parts
Kudat is dedicated to provide our clients with genuine spare parts with the highest quality, exact fitness and appropriate function. With our global distributor network, you are guaranteed with fast deliveries and services, wherever you are. Please submit your spare parts request to us, and list products name, model, equipment serial number, description of required parts. We guarantee that your request will be handled quickly and appropriately.

Installation & Maintenance
Kudat is able to provide you with the overall installation of complicated machinery and equipment, for example--crawler crane,concrete batching plant, crushing machines etc.,allowing you to start the normal operation of cranes immediately. After installation, we will make inspection of the whole machine, operate equipment, and provide you with testing data reports of installation and operation.

Training
Kudat offer perfect facilities and comfortable environment and can provide training service to different users. The training sessions include product training, operation training, maintenance know-how, technical know-how training, standards, laws and regulations training and other trainings, all of which are tailored to fulfill your individual needs. Training programs can be conducted in our factory field, or at the client's site.

Technical Advice
Kudat can also help clients coordinate with trained service personnel to provide you detailed and extensive knowledge about your specific machine. With our technical advices, your machine service life can be significantly prolonged and sustained with high capacity.
