High Quality 4G WiFi Router 12V DC Power Support 60 User WiFi Router 4G LTE with SIM Card Slot

Product Description

Product Description HUASIFEI HR204 wireless router is a wireless communication product developed based on 4G network requirements. Support 4G LTE global frequency band. Support 4G LTE CAT 6 or CAT 12 high speed access to the Internet. It can realize the maximum downlink bandwidth of 300Mbps~600Mbps and the maximum uplink bandwidth of 50Mbps~150Mbps. It supports 2 Gigabit Ethernet ports, providing stable and high-speed wireless broadband access for home and business users. Support for WIFI 2.4GHz/5GHz dual-band function to meet the access and sharing needs of more than 60 users' WIFI hotspots.

Product features.
Power supply. DC +12V/1.5A . Supports 2*2 MIMO or 4*4 MIMO internal antenna or external antenna. Wireless Mobile Broadband 3G / 4G LTE connection. Support 3G/4G LTE global frequency bands. System crashes and automatically recovers. The system automatically maintains the data link and is permanently online. Supports Multiple VPN tunnels for data encryption . Simple and beautiful, fashionable shell. Easy to use and easy maintenance
User friendly web interface for user interaction. Supports Remote Management Platform. Supports local web UI and remote FOTA update firmware. Operating system
Built-in OpenWRT 18.06 operating system. Support user secondary application development.

Detailed Photos
specifications

Cellular feature
3G/4G LTE data connectivity	It provides data connectivity on LTE-FDD, LTE-TDD, DC-HSDPA, HSPA+, HSDPA, HSUPA and WCDMA networks.
3G/4G LTE Frequency bands	Version E. LTE-FDD: B1/B3/B5/B7/B8/B20/B28/B32 LTE-TDD: B38/B40/B41/B42(Optional) /B43(Optional) WCDMA: B1/B3/B5/B8 Verison A. LTE-FDD: B2/B4/B5/B7/B12/B13/B14/B25/B26/B29/B30/B66/B71 LTE-TDD: B41/B48 Version LA. LTE-FDD: B2/B4/B5/B7/B8/B28/B66 LTE-TDD: B42(Optional) /B43(Optional) WCDMA: B2/B4/B5/B8 Remarks. More Bands Demands please contact with us.
3G/4G LTE Data rates	4G LTE--CAT 6 LTE-FDD Max 300M(DL) , Max 50Mbps (UL) LTE-TDD Max 226M (DL) , Max 28Mbps (UL). 4G LTE-CAT 12 LTE-FDD. Max 600Mbps (DL),Max 150Mbps (UL) . LTE-TDD. Max 430Mbps (DL),Max 90Mbps (UL). HSPA+. DL 42Mbps, UL 11.2Mbps. WCDMA. DL 384Kbps, UL 384Kbps
3G/4G LTE Transmitting Power	Class 3 (23 dBm±2 dB) for LTE-TDD bands Class 3 (23 dBm±2 dB) for LTE-FDD bands Class 3 (24 dBm+ 1/-3 dB) for WCDMA bands

LTE features	CAT 6 version. Supports 3GPP Rel-12 CAT 6 FDD and TDD Supports uplink QPSK and 16 QAM modulation. Supports downlink QPSK , 16 QAM and 64 QAM. Supports 1.4MHz to 40MHz (2 CA) RF bandwidth. CAT 12 version. Supports 3GPPRel-12 CAT 12 FDD and TDD. Supports uplink QPSK ,16 QAM and 64 QAM modulation. Supports downlink QPSK , 16 QAM ,64 QAM and 256 QAM. Supports 1.4MHz to 60MHz (3 CA) RF bandwidth.
UMTS features	Supports 3GPP Rel-9 DC-HSDPA,DC-HSUPA,HSPA+,HSDPA,HSUPA and WACDMA Supports QPSK ,16 QAM and 64 QAM modulation.
Antennas	Supports 2*2 MIMO or 4*4 MIMO internal antenna or external antenna with 50 Ω impedance.
SIM card feature
SIM card	Supports 1* SIM slots, 1.8V / 3V . Or 1* eSIM card. ( Optional )

Company Profile
HUASIFEI is a manufacturer professional in R&D and producing network equipments, products are included OpenWRT 4G5G wifi router, Vehicle 5G router, outdoor CPE, indoor CPE,MESH Router ,WIFI-6 Router ,4G OTT 4G5G Modem.HUASIFEI .with 50 people R&D team and around 700 people in factory, 20,000 Square meters production scale, is very skilled at processing OEM/ODM design, also builds the long term cooperation with Mediatek, Broadcom,Qualcomm, capably offering good quality product and fast after-sale service.Till now, HUASIFEI's products have exported to over 30 countries. Packaging & Shipping
FAQ Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: Sample needs 1-3 working days, mass production time needs 3-5 weeks based on order quantity.
Q3. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available.
Q4. Do your products meet our standards?
A: Yes, almost all our products have CE,ROHS,FCC,etc.
Q5. How to proceed an order?
A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order. Then we arrange the production.
Q6. How do you ship the goods and how long does it take to arrive? A: We usually ship by Ali-Logistics, DHL, UPS, Fedex, TNT, EMS, SF Express or your designated forwarder. It usually takes 3-7 days to arrive. Airline and sea shipping also optional. Q7. What is your payment term? A: We have Ali- pay, T/T, Visa,Western Union payment terms options, you can choose the one which is convenient or effective for you ! Q8. Can you customized logo and packaging? A: Yes, OEM/ODM are acceptable. Our design team will help you design as your requirement.
