Basic Info.
Certification
ISO, CB, CE, FCC RoHS PSE MSDS
Application
Home, Industrial, Commercial, Outdoor
Specification
Normal, 315*190*220mm
Capacity
210000mAh, 3.2V=672wh
AC Output
100V/120V/220V/230V/240V, 50/60Hz, 700W
Type C Output
Pd18W; Pd100W
AC Charging
400W @ 2.18hours
Solar Charging
MPPT, 10-60V/10A/400W Max
Transport Package
Neutral Packing Box
Origin
Guangdong, China(Mainland)
Production Capacity
30000PCS/Month
Packaging & Delivery
Package Size
38.00cm * 25.50cm * 34.50cm
Package Gross Weight
9.480kg
Product Description
700W 672Wh Rechargeable LiFePo4 Battery Portable Power Station Solar Energy System with UPS function Product Description
1. Safety First - Built-in Lifepo4 Battery with 2000times lifecycles . - Battery Management System (BMS) constantly monitors the voltage, current, and temperature. Protection:Over-Voltage /Low-Voltage /Over-Current /Short-Circuit/Over-Load/Over-Temperature 2.Power Inverter - UPS Functions(automatically switch to the battery-powered supply mode within 20ms)
- Power Boost Function
- Bidirectional Inverter 3.Fast Charging
- AC Charging 400W: 2.18hours - Car Charger 13V9A=117W: 6.25hous or 24V/8A=192W :4 hours - Solar Panel=MPPT 10-60V, 10A/400W(MAX), around 2.18 Hours
Battery Capacity | 210000mAh, 3.2V=672Wh |
Built-in Battery | LiFePo4 battery |
Inverter | Pure Sine Wave-700W |
Fully Charged Time | AC charging 400W Max: 2.18 hours Car charger 13V/9A: 6.25 hours Solar panel 400W: 2.18 hours |
Input Recharging | AC Charging: 400W Max Solar Panel: MPPT, 10-60V/10A ,400W Max |
DC Output | 2 x DC5521: 13.5V/10A |
AC Output | AC Power: 700W Rated, 1400W Peak 100V~240V, 50/60Hz (Can be customized) |
USB Output | USB-A: 2x PCS*QC18W |
Type-C Output | 1PCS*PD18W 1PCS*PD100W |
6W Ultra Bright LED | Flashlight/Blink/SOS |
Power Indicator | LCD Display |
Lifecycles | 2000 times |
Dimensions (Length*Width*Height*Total Height) | 315*190*220mm |
Weight | about 9.48kg |
Charging Mode | CC/CV |
Accessories | AC Cable/Car charger/User manual |
Solar Panel (purchase separately) | Recommend 18V400W |
Solar Bag (purchase separately) | Recommend 18V300W |
K700 Portable Power Station, Power Outdoors
FAQ
Q: What devices can K700 model power?
A: Please note that the AC output port can only charge/power devices that operate at less than 700-Watt; Once exceeding, the K700 model will shut off and start protection automatically. Please refer to your device specification before purchase.
Q: How to know the working times for my device?
A: Working time = 672Wh* 0.85 / operating power of your device
For reference, assuming power consumption of your device is 60W (might be a box fan), working time will be 672Wh*0.85/60w=9.5 hrs (rough calculated) .
Q: How long does it take to full charge this power station?
A: Within 2 hours from an AC wall outlet; Also another two recharge backup choices for your convenience, recharge from car port around 9 hours, and around within 4 hours from a 300W solar panel (Sold Separately). Detailed Photos
