Vinegar Residue Fertilizer Making Equipment Compost Bio Fertilizer Granule Making Production Line

Product Description

Product Description
Organic Fertilizer Production Line is mainly used to produce different organic fertilizers that are derived from animal manure, agricultural waste, industrial waste and kitchen waste, etc. After safety disposal and fermentation, raw materials are made into bio-organic fertilizers that contain a variety of organic acids, peptides and rich nutrients including nitrogen, phosphorus and potassium. Organic fertilizers not only provide comprehensive nutrition for plants and crops, also with long fertilizer effect, which can increase and update the soil organic matter, promote microbial breeding, and improve soil chemical and physical properties and biological activity.

Raw Material
1.Kitchen waste: bones, pericarp, vegetable leaves and eggshell, etc.
2.Agricultural waste: corn stalk, rice stalk, wheat straw, soybean meal, cotton meal, peanut shell powder, Mushroom residue, etc.
3.Municipal sludge: waterworks sludge and river sludge, etc.
4.Industrial waste: vinasse, biogas residue, vinegar residue, Bean dregs, sugar scum, oil residue, shell powder, amino acid humic acid, etc.
5.Animal manure: chicken manure, duck manure, Goose manure, pig manure, cow manure, horse manure, sheep manure, etc.
Product Parameters

No	Production equipment	Process	Power	Fearures
1.	fermentation device	harmless treatment	31-120kw	fermentation of organic fertilizer
2.	compost pretreatment	materials preparation	5.5-50kw	qualified powder raw materials
3.	further granulation	fertilizer granulating	15-100kw	beautiful fertilizer particles
4.	dryer and cooler	keep granules moisture	15-120kw	particle hardness
5.	sifting and packaging scale	final packing	1-30kw	finished product

Detailed Photos
Flow Process Diagram
Fermentation and compost process → crushing process → mixing process → granulating process → drying process → cooling process → screening process → packaging process
Fermentation process
The fermentation of bio-organic raw materials plays quite a basic role in the whole production.Sufficient fermentation lays a solid foundation for the quality of the end products. Groove type compost turner can thoroughly compost and turn high-stacked fermentation materials with large production capacity.Self-propelled compost turner can work freely outside or inside the factory,greatly increasing the speed of aerobic fermentation.It is natural compost at the open place or in the compost tank with ceil; normally the compost fertilizer need about 5-8 days to ferment, and become purer organism.
1.Crushing process
Our semi-wet material crusher with high-speed rotating blade is a new type and high-efficiency single reversible crusher,and has strong adaptability to high water-content organic matter.Semi-wet material crusher is widely used in the organic fertilizer producing process and it performs well in crushing chicken manure, sludge and other wet materials. Crushing fertilizer raw material into small size that can go further process for granulating.
This fertilizer crusher greatly shortens the production cycle of organic fertilizer,and saves production cost.
2.Mixing Process
After crushing,auxiliary materials are added into the materials according to the formula and mixed in the mixer.We provide single-shaft mixer and double-shaft mixer for you to mix the materials evenly.
3.Granulating Process
This machine can help reduce the energy that is wasted in the drying process,because granules can be immediately screened after the granulation process.The purity of the organic fertilizer granules can reach as high as 100%,which makes the pure organic fertilizer production come true and meet the needs of the customers directly.This machine is featured with low energy consumption,low production expenses and high production quantity and is considered as your best choice for pure organic fertilizer production.
4.Drying Process
Rotary drum drying machine is mainly used for drying the fertilizer with a certain degree of humidity and particle size. Materials are transported to the drum by belt conveyor.Rotary dryer is suitable for large,medium,and small farms.Different sources of heat are applied,such as coal gas producer, directly/indirectly heated stove,etc.according to different drying requirements of
5.Cooling Process
Rotary drum cooler is used for cooling fertilizers to make fertilizer particles stronger.
6.Screening Process
We provide high-quality and good-performance rotary drum screening machine which is used for separating the returned materials and the finished products.The returned materials will go back to fertilizer crusher for further process,while the finished products are conveyed to fertilizer coating machine,or directly transported to automatic fertilizer packager.
7.Packing Process
The finished products enter into the packing machine through the belt conveyor.The fertilizer packaging machine packages finished products quantitatively and automatically.
Overseas Scene
Packaging & Shipping
About Us
About our company
Gofine Machine, establish in 2010, located in Longgang Developed Zone of Xingyang City, Henan, China, specially engaged in producing fertilizer production machinery, animal feed machinery, waste recycling machinery and trading in building machinery and food machinery and wood machinery; we have heavy standardization industrial plants with area 60000 square meter, bring advanced large metal processing equipment, including the 10 sets CNC machining center, 3sets laser cutting machine, and other equipment reaching total 100 sets; we have get known by the ISO9001-20001 certification and CE certification; Welcome you to know us more on our machine and our technology.
We take "Quality First and Customer Supreme" as our business philosophy, adhere business idea"Honesty and Excellence" and spirit of "Practical and Innovative", act "Attitude is everything" to our business and each client.
FAQ
1. Why choose us?
Gofine Machine is a professional equipment manufacturer, that integrates scientific research, production, sales, import, and export. One-stop procurement service, support customized solutions.
2. How can we guarantee the quality?
We have a strict quality control system to ensure the factory quality of each product.
3. What can you buy from us?
Gofine Machine produces fermentation equipment, compost-turning machines, crushing mixers, granulators, screeners, packaging machines, and other commercial equipment, etc.
4. What services can we provide?
We have professional overseas installers responsible for installation, commissioning and free training. Professional personnel are waiting for you online 24 hours a day.
5. How to choose equipment?
We have a professional technical team to customize reasonable solutions for you and support customized services.
