Infitech Hot Sale Painting Equipment Car Auto Paint Spray Booth
| US$6,999.00-15,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
IT-502
Substrate
Steel
Brand
Infitech
Coating
Painting
Airflow Direction
Fully Undershot-type
Heating Mode
Diesel
Paint Mist Treatment
Dry-type
Condition
New
Plenum Height
400mm
Walls
50mm Rock Wool Panel
Lighting
LED Lamp
Brightness
>1200lux
Filter
High Efficiency Filters
Fan
Direct Drive Fan, 5.5kw Motor
Air Volume
20,000m3/H
Empty Loaded Air Speed
+/-0.20m/S
Controls
CE Standard Control Box
Transport Package
Polyfoam and Metal Frame
Specification
6900 x 4000 x 2800mm
Trademark
INFITECH
Origin
Guangzhou, China
HS Code
8419899090
Production Capacity
900 Sets/Year
Product Description
INFITECH hot sale painting equipment car auto paint spray boothDesign
Technical parameters
| INFITECH hot sale painting equipment car auto paint spray booth | |
| Design standard | BS EN 13355: 2004 + A1: 2009 BS EN 60204: 2006 + A1: 2009 |
| Internal dimensions | 6900 x 4000 x 2800mm (L X W X H) |
| External dimensions | 8470 x 4110 x 3260mm (L X W X H) |
| Plenum height | 400mm |
| Entrance door | 1 set, 3200 X 2700 mm (W X H) |
| Personnel door | 1 set, 800 x 2000 mm (W X H) |
| Ceiling lighting | 8 sets, each 4 X 18W, 576W total, LED lamp |
| Sidewall lighting | 10 sets, each 2 X 18W, 360W total, LED lamp |
| Brightness | >1,200LUX |
| Purification | Pre-filter, ceiling filter, floor filter |
| Air intake | Direct-type turbine fan, 5.5KW, SIEMENS motor |
| Air exhaust | Direct-type turbine fan, 5.5KW, SIEMENS motor |
| Air volume | 20,000m3/h |
| Empty loaded air speed | +/-0.20m/s |
| Controls | CE standard control box, with stack light |
| Rated power | 13KW |
Features
| Airflow • Full downdraft for spray and cure • Controlled airflow ceiling | Construction • White pre-coated galvanized steel • Dual-skin insulated panels filled with rock wool, 50mm thick • 400mm high plenum • 350mm high raised basement, full grids |
| Doors • 3-wing entry door • Personnel door with observation window | Heat • Intake and exhaust motors, 5.5kw, SIEMENS motor • Diesel burner |
| Filtration • Pre-filter: G3 grade pre-filter plate filter • Ceiling filter: F5 grade filter cotton, Model SP-600G • Floor filter: G2 grade fiberglass paint arrestor filters | Controls • PLC controller, pressure gauge • With stack light Functions: Painting, warm painting, flash, baking, lighting, emergency stop switch, failure indication, over-temperature alarm indication, baking delay stop protection, motor over-load and over-current protection, fan and heating system interlock |
Product details
Packaging and loading
Company information
Guangzhou Infitech is professional manufacturer of customized European standard spray booths in China. We stick to European standard for spray booth since the business started. What we supply ranges from initial design and layout, technical consultation, manufacturing through to installation and maintenance. We pride ourselves in delivering customized products that suit your customers' individual needs.
