Heavy Duty Universal Rotary Head and Knee-Type Milling Machine,

Heavy Duty Universal Rotary Head and Knee-Type Milling Machine,

US$4,000.00-30,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
FX6145
Milling Cutter Type
Angle Milling Cutter
Milling Cutter Structure
Indexable Type
Controlling Mode
Manual
Automatic Grade
Semiautomatic
Precision
Precision
Certification
CE, ISO 9001
Condition
New
Heavy Duty Milling Machine
Work
Transport Package
Veneer Case
Specification
CE Standard
Trademark
HAVEN
Origin
China
HS Code
84596990
Production Capacity
100 Units/Month

Product Description


FX6145 Heavy Duty Universal rotary head and Knee-Type Milling Machine
(Picture for reference)
This kind milling machine is developed by absorbing the feature and technology of advanced European countries in the middle period of 1990s. It has strong loading capacity, large specification parameter, high rigidity and unprecedented structure precision, its quality is obtained according to several years' combination design or transformation design, the birth of this kind of product has made the dream of milling machine to pursue senior, high level knee-type milling machine come true.
With optional accessories as dividing head, rotary table, machine vice, boring and facing milling head, milling chuck, etc. Its machining scope/capacity greatly enlarged. X6145/1: Digital readout(2 dimensional or 3 dimensional) is added to X6145 machine which can improve the machining accuracy and producing efficiency.
Product Name: Universal Knee-type Milling Machine
Product Type: FX6145
Work table area(width*length): 500*1800mm
T-slots(number of slot-width*pitch): 6-18*63mm
Work table max. weight of workpiece: 1500Kg
work table swivel angle: ±45°
Max.stroke longitudinal/transversal/vertical(power-driven): 1320/345/600mm
Max.stroke longitudinal/transversal/vertical(manual): 1330/360/630mm
Spindle motor power: 15Kw
Spindle taper: XT50
Spindle speed range: 18 steps 35.5-1800r/min

WHY CHOOSE HAVEN BRAND MACHINE:
1) Hihg quality with competitive price
2) 15 years export experience
3) CE,SGS, ISO Certificated
4) OEM SERVICE AVAILABLE
5) 24 HOURS' ONLINE SERVICE (MSN,SKYPE)
6) 14 months quality warranty (after B/L date)
7) Over sea engineers available for problem shooting

Our Target: BRAND HAVEN
High quality;
Assured Delivery;
Vigorous innovation;
Efficient Cooperation;
Noblesse Oblige
