Good Price 49m 50m Concrete Boom Pump Boom Concrete Pump Truck Mounted Cement Concrete Pump Truck Pump Machinery Pump Truck

Product Description

Chongqing Friends International Trade Co., Ltd.
Our factory is professional manufacturer in truck area, customized trucks can be made. As Qingling ( China ISUZU ) big First Level Dealer, we guarantee superior technical support service and our trucks are Brand-New with High-quality.
China ISUZU Qingling GIGA series heavy duty truck equals to Japan ISUZU GIGA series heavy duty truck, compatibly in loading capacity, spare parts, technical support and after-sales service, same excellent performance but more cost-effective and competitive price.
Product Description I. Details of 8x4 12 wheels Japan China ISUZU Qingling GIGA CYZ 50m 8×4 Heavy Duty Diesel Concrete Pump Truck
Function: Concrete Pump Truck ( also called construction concrete pump truck, concrete construction pump, transported concrete pump ) is a vehicle designed primarily for pumping the transported mixed concrete for various building construction purposes. It is mostly used in the construction site ( high/medium building, bridge, expressway/road, light rail, the small site and bridge projects, very suitable for long distance and narrow construction conditions ) with the dump truck , boom truck, water truck, concrete mixer truck .....
Types: 1. According to vehicle size, there are medium concrete pump truck, heavy-duty concrete pump truck. 2. According to chassis drive type, there are 4X2 concrete pump truck, 6X4 concrete pump truck, 8X4 concrete pump truck.
Features:
1. Using Japanese technology ISUZU GIGA Chassis, super power, larger displacement, with Stronger Engine performance.
2. Remove the urea system and cancel DPF.
3. Quality test from the production to the finish of the whole truck.
4. Professional and experienced technical team support to provide customized trucks with high quality & reasionalble price.
5. Genuine spare parts supply.
6. Prompt delivery. All the truck will be polished with wax before shipping and accordingly the truck type and destination port to choose the most suitable and cost-effective shipping way.
Product Parameters II. Specifications

Product name	ISUZU GIGA 8×4 12 Wheelers Mixer 50m Concrete Machinery Heavy Duty Concrete Pump Truck 50m Mounted Concrete Boom Pump Truck
Vehicle Dimensions, Weights & Capacities	Chassis brand	ISUZU GIGA CYZ VC61 VC66
	Overall dimension (L*W*H)	13600*2550*3970mm
	Wheelbase	1850+4575+1370mm
	Total weight	38,000 Kgs
	Axle loads	7500*2/26000Kgs (Two-Axis Group)
Chassis	Drive mode	8x4
	Cabin type	Standard roof one bed
	Seats	2 seats
	Steering	LHD
	Tyres	12+1 spare tyre
	A/C	Air conditioning
Engine	Enging model	6UZ1, 6WG1
	Fuel and engine Type	Diesel, 6 cylinders in-line
	Horse power	380HP, 420HP, 460HP, 520HP
	Displacement	9.839 L, 15.681L
Other Standard Configurations	1	Power Steering System
	2	Air Conditioning
	3	ABS, Automatically Air-cut Brake
	4	Tubeless tyres
	5	Retro-Reflective Marking
	6	Free Maintenance Battery
	7	Central Lock
	8	Power Window
	9	USB, Radio
	10	Widened Bumper
	11	Aluminum Alloy Gas Tank
	12	Front Chrome Kit for option
Tops Parameters	Vertical height	50m
	Horizontal length	44.6m
	End rubber conveyor hose length	3m
	Slewing angle	±360 °
	Other details	Pls contact with us

Detailed Photos III. Photos
