8 Liter /Hour High-Temperature Desiccant Dehumidifier
| Negotiable | 1 Set (MOQ) |
Basic Info.
Model NO.
CFT
Timing Function
With Timing Function
Type
Desiccant Dehumidifier, Floor Standing
Name
Industrial Cabinet Desiccant Air Dehumidifier
Rated Dehumidification Cap
8-100 Kgs/H
Rated Cooling Cap
14-165kw
Power Suplly
220/1pH/50Hz, 380/3pH/60 Hz etc, Choose by Client
Comprssor Type
Hermetic Scrol
Compressor Rated Power
3.75-9*5kw
Exchanger Type
Hydrophilic Film Aluminum Fin with Copper Tubes
Air Flow
5000-66000 CMH
Refrigerant
R410/R22/R407c etc Choose by Client
Weight
220-1160kgs
Dehumidifier Function
Adjustable Humidistat
Classification
Dehumidification
Dehumidifier Type
Cooling
Power Type
AC Source
Water Shortage Power-off Protection
With Water Shortage Power-off Protection
Humidifier Type
Industrial Dehumidifier
Humidity Control
Auto and Manual
Transport Package
Plastc+Foam+Woden Case
Specification
1unit/case
Trademark
Headpower
Origin
Guangdong Foshan
Production Capacity
500 Units/Months
Product Description
1)The Feature of 8 liter /hour high-temperature desiccant dehumidifier1.Headpower company has rich experience in design and manufacturing of refrigeration dehumidifiers.Its series of refrigeration dehumidification equipment for air dehumidification are applicable for places with need of dehumification, such as national defense engineerings,civil air defense engineerings,tabacco and petrochemical industries,metrostations,aerospace,decontamination engineerings,lab,telecommunication equipment rooms,archives rooms, foor rooms,pharmaceutical and film workshops,and specialty glass manufacturing.
2.Headpower dehumidifiers include series of regular dehumidifiers,pipe dehumidifiers,heating pipe dehumidifiers, dehumidifiers forcoastal engineerings,dehumidifiers for tabacco storehouses, dehumidifiers for air-conditioning of undergroud engineerings,full fresh air dehumidifiers,and united dehumidifiers
2)Product model:
| items type | CFT8 | CFT10 | CFT16 | CFT20 | CFT25 | CFT32 | CFT40 | CFT50 | CFT60 | CFT80 | CFT100 | ||
| dehumidity capacity | kg/h | 8 | 10 | 16 | 20 | 25 | 32 | 40 | 50 | 60 | 80 | 100 | |
| cooling capacity | KW | 14 | 16.6 | 28 | 33 | 42 | 56 | 66 | 83 | 99 | 132 | 165 | |
| power supply | 220V/1PH-50HZ 380V/ 3PH-50HZ | 380V/3PH-50HZ | |||||||||||
| protection devices | high &low pressure switch,over load protector,phase order protection,internal over-heat protector ,frequent boot protector | ||||||||||||
| operation and control | microcomputer control automatically,failure warning,trouble self-checking, operation balance,Timer on/off | ||||||||||||
| compressor | type | hermetic scroll compressor | |||||||||||
| power | KW | 3.75 | 4.5 | 3.75×2 | 4.5×2 | 3.75×3 | 3.75×4 | 4.5×4 | 4.5×5 | 9×3 | 9×4 | 9×5 | |
| heat exchanger of air side | exchanger type | copper tubes with aluminum fin | |||||||||||
| fan type | ultra-low-noise centrifugal | ||||||||||||
| air flow | m3/h | 2600 | 3200 | 5200 | 6400 | 7800 | 10800 | 12800 | 16000 | 19200 | 25600 | 32000 | |
| external static pressure | Pa | 0/100 | 0/120 | 0/150 | 0/180 | 200 | 220 | 250 | 280 | 350 | 350 | 400 | |
| motor power | KW | 0.55 | 0.75 | 0.55×2 | 0.75×2 | 2.2 | 3 | 4 | 5.5 | 7.5 | 11 | 15 | |
| heat exchanger of outdoor side | exchanger type | hydrophilic film aluminum fins with copper tubes | |||||||||||
| fan type | low-noise axial | ||||||||||||
| air flow | m3/h | 5000 | 6000 | 11000 | 13000 | 17000 | 22000 | 25000 | 33000 | 39000 | 54000 | 66000 | |
| motor power | KW | 0.25 | 0.28 | 0.25×2 | 0.28×2 | 0.55×2 | 1.1×2 | 1.1×2 | 0.75×3 | 1.1×3 | 1.1×4 | 1.1×5 | |
| refrigerant/volume control | R22/ thermostatic expansion valve | ||||||||||||
| operation noise | dB(A) | 56 | 59 | 62 | 63 | 65 | 66 | 66 | 68 | 70 | 71 | 72 | |
| weight | kg | 220 | 240 | 320 | 380 | 450 | 520 | 600 | 680 | 810 | 980 | 1160 | |
| dimensions (L×W×H) | indoor unit | mm | 1050×600×1650 | 1100×600×1700 | 1450×650×1700 | 1600×800×1800 | 1800×800×1800 | 2000×850×1980 | 2100×900×2050 | 2100×1160×2200 | 2200×1200×2200 | 2400×1380×2200 | 2500×1600×2400 |
| outdoor unit | mm | 840×840 ×950 | 840×840 ×950 | 1050×1050×1300 | 1050×1350×1300 | 1200×1350×1300 | 2250×1050×1150 | 2300×1100×1250 | 2300×1100×1500 | 2300×1200×1400 | 2300×2100×2000 | 2300×3100×2000 | |
| Note: 1. The above parameters are measured under the following conditions: indoor air temperatureDB27 ºC,WB21.2ºC; For air cooled type, outdoor air temperature DB35ºC,WB24ºC; For water cooled type, the inlet/outlet water temperature is 30ºC/35ºC. 2. The specifications are subject to change without notice for improvement. 3. Any special requirements please notify us in advance. | |||||||||||||
4)Packing and shipping
5)Our company file
