Table 2000X425mm, Knee-Type Plain Horizontal Milling Machine

Product Description

1. This HM425 knee-type plain horizontal milling machine is suitable for milling the flat surfaces, the inclined surfaces, the angular surfaces and the slots with the disc cutters, the angular cutters, the formed cutters and the face-milling cutters. When equipped with the dividing head, this plain milling machine can perform milling operations on gears, cutters, helix grooves, cams and tub wheel;
2. On this plain milling machine, the base and the column are made of one-piece high-density resin grey iron castings to ensure the whole machine has high rigidity. All the guideways on this plain milling machine are hardened with high-frequency quenching and precision ground to keep long term stable accuracy;
3. Large worktable as 2000x425mm to carry large workpieces. The worktable of this plain milling machine can perform manual feeds, power feeds and rapid traverses in all the longitudinal, cross and vertical directions;
4. Cantilever mounted control console provides convenience for the operations;
5. When equipped with the dividing heads, the vertical milling heads, the universal milling heads and the machine vises, this plain milling machine can extend its machining scope;
6. On customer request, a Digital Readout system can be mounted to monitor accurately the real-time movements of the worktable to ensure the high-precision machining.

Specifications		Unit	HM425
Worktable size (Length x Width)		mm	2000 x 425
Worktable travels	Longitudinal (Manual/Power)	mm	1200/1180
	Cross (Manual/Power)	mm	410/400
	Vertical (Manual/Power)	mm	460/450
Feed steps of worktable			15
Feed speed range	Longitudinal	mm/Minute	10 - 1250
	Cross	mm/Minute	10 - 1250
	Vertical	mm/Minute	2.5 - 315
Distance between spindle centerline with worktable		mm	30 - 480
Spindle speeds		RPM	18 - 1400, 20 Steps
Main motor power		KW	11
Overall size, L x W x H		mm	2614 x 2497 x 2043
Net weight, Approx.		KG	5300
