HDMI USB 3.0 Video Capture Card 1080P Video Recorder for Obs Gaming Live Streaming HDMI Capture Card

Product Description

HDMI USB 3.0 Video Capture Card 1080P Video Recorder for OBS Gaming Live Streaming HDMI Capture card

HD Video Capture This Video Capture lets you record to USB storage and ability to record HDMI, YPBPR video source. Not for live streaming. don't work with computer directly.

USB 2.0 Storage Storage Media USB Flash Disk, Portable Hard Disk, not work with USB3.0 devices. Note: The exFAT format is not supported.

Easy to use Just press one button to record / stop, Including Video editing software(ArcSoft Showbiz3.5)to edit the splitted MP4 files together; License key is on the back of the bag including a CD driver.

Broad Compatiblity Record gameplay from the PS 4, PS3, Xbox 360, Xbox One, Nintendo Switch and Wii U etc. Capture every second of your video reference, including image and voice.

Breif Introduction
HDMI USB3.0 HDMI Video Capture Card has the characteristics of simple installation, convenient carrying, superior performance and good compatibility. It can capture an HDMI 1080p60 input and output signal; compatible with Windows, Linux, MacOS X and USB 3.0 interfaces; compatible with many USB 3.0 chip sets (Intel, Renesas, etc.), and PCIe Gen1.1 x1, extending USB 3.0 interface. HDMI video capture conforms to UAC standard, no need to install driver and make settings; It is easy to use; plug and play.

Product features
No need to install driver; plug and play. Compatible with Windows, Linux, OS X operating system. Throughput capacity of USB3.0, 300-350 Mb/s and compatible with USB 2.0. The transmission and processing of audio and video is through a dedicated device that does not take up CPU memory. It can capture a single channel HD HDMI video signal. It can automatically detect the input video format and adjust the output video size and frame rate. The input and output signal can reach 1080p/60 Hz. Compatible with UVC video capture and YUV422 video output.

Main interface port	USB3.0*300-350MB/s , USB2.0* 40MB/s
Input	HDMI interface
HDMI input format	480i/480p/576i/576p/720p60/1080i50/1 080i60/1 080p24/25/30/50/60
Output resolution	640x480/720x480/720x576/768x576/800x600/1024x768/1280x720/ 1280x800/1280x960/1280x1 024/1 368x768/1 440x900/1 600x1200/1 680x1 050/1920x1 080/1920x1200/640x360/856x480/960x540/1024x576
Frame rate	25/29.97/30/50/59.94/60fps
AV Capture	Standard UVC and UAC
Support OS	Windows 7 Windows Server 2008 R2Linux (Kemel version2.6.38 and above)OS X(10.8 and above)
Software compatibility	Windows Media Encoder(Windows) Adobe Flash Media Live Encoder(Windows, OS X) Real Producer Plus(Windows)VLC(Windows, OS X,Linux) Quick Time Broadcaster(OS X) Quick Time Player(OS X) Wirecast(Windows, OS X)Potplayer(Windows)and etc. Developmentinterface compatibility DirectShow(Windows),DirectSound(Windows),V4L2(Linux), ALSA(Linux)OS X(Quick Time) Real Producer Plus
Product size	98*56*16(L/W/H,mm)
Power	≤2.5W
Working temperatur	0~50ºC
Storage temperature	-20~70ºC
Storage humidity	5%-90%

Applications 1. Software: Arcsoft Showbiz
2. Video Editing: Timeline/Storyboard edit, Split / Divide Scenes, Multi Trim Scenes
3. Operating System: Windows 8 (32/64 bit), Windows 7 (32/64 bit), Windows Vista (32/64 bit)
4. CPU: Intel Core 2 Duo 2.8GHz, AMD Athlon 64X2 Dual Core 3.0GHz
5. Memory: 4 GB RAM
6. Graphics Card: VGA card with support for DirectX 10.0c or above
