Custom Optic Fiber MPO Pigtail MTP Fiber Array Assembly
| US$1.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
customized
Connection Structure
Customized
Material Shape
Customized
Allowed Lateral Pressure
Customized
Allowed Tensile Strength
Customized
Core
Customized
Certification
RoHS, ISO9001
Brand
3V-Tech
Sheath Material
Customized
Channel Number
Customized
Fiber
Sm,mm or Customize
Connector
LC,Sc,FC or Customize
Mt
Us Conec or Senko
Transport Package
Requested
Specification
Standard for Export
Trademark
3V-TECH
Origin
China
HS Code
8517623100
Production Capacity
1000000PCS/Month
Product Description
We can support to produce for customized order based on provided sample/drawingFeatures:
8-12 core fiber available
small in size ,easy to management
loss mode: Low loss;Standard Loss
Different in fiber connection according to QSFP requirement
Manufacturer of MT:US Conecter or SENKO Optional
Applications:
QSFT module
Data Center
Specifications:
| Fiber type | single mode | multimode | |
| Standard insertion loss | typical(dB) | 0.35 | 0.35 |
| Maximum(dB) | 0.75 | 0.60 | |
| Low insertion loss | typical(dB) | 0.20 | 0.20 |
| Maximum(dB) | 0.35 | 0.35 | |
| Return loss (dB) | ≥60(APC) | ≥20(PC) | |
| ≥50(PC) | |||
| Tensile Strength (kgf ) | 10 | ||
| Durability (dB) | ≤0.2 500 matings | ||
| working temperature (ºC) | -40 ~+85 | ||
| Test wavelength (nm) | 1310 | 850 | |
