Small Combine Reaper/Grain Combine Harvester/Combine Reaper Binder Harvester

Product Description

Small combine reaper/grain combine harvester/combine reaper binder harvester Specification:

Product name	grain combine harvester
Model	ACME-4LZ-0.3
Working Types	Harvesting rice, operated by one person
Weight(kgs)	275	Cutting width(mm)	1200
Overall Dimension	2800×1400×1350(L×W×H)(mm)
Packed dimension	1320*960*1210mm, 1370*1220*1250mm
Engine	173F(3.8KW) gasoline Engine
Harvesting	Harvester working in Paddy field with paddy working wheel
Harvesting Rate	≥600m2/h	Loss Rate	≤3.5%
Broken Rate	≤0.1%	Rate of rice with straw	≤5%
Fuel Consumption	≤0.8L/H	Feeding Volume	0.3kg/s

Introduction:
Light weight, dismountable, weight for whole machine is about 200kg, and can be dismounted into three parts: host machine,
threshing . Cylinder, and harvester head, thus much more convenient to carry to paddy field where there is no road nearby.
Wide range of application, this item can be both used for dry land and water paddy field. Those big or large harvester cannot work
in water paddy field, as it will get stuck in water paddy field because of its heavy weight, but this 4LZ-0.3 mini harvester has no
such problem, thus it is very suitable for those southeast countries where there are so many water paddy fields.
structure
Main five components for this 4LZ-0.3 mini harvester are: harvester head, threshing part,operating part, power system,
and walking system.
1. Harvester head consists of head frame, cutting knife, transmission part, convey etc.
2. Threshing part consists of threshing bin, screen, rice output bin, rice barrel, threshing assembly etc.
3. Operating part consists of clutch handle of transmission system, gear level, the gasoline engine throttle lever, regulating handle for head up and down etc.
4. Power system consists of fuel tank, silencer, air filter, starter, PTO shaft etc.
5. Walking system consists of belt transmission clutch, steering clutch for left and right, gear box, walking wheels etc.
