Swiss Type CNC Lathe Metal Milling Fanuc Controller Tck6350b

Product Description

Product Parameters

Project		Units	Specifications	Remarks
Maximum turning diameter on bed		mm	720
Maximum cutting length		mm	2000
Maximum cutting diameter		mm	500	12 stations (cutter head opposite side diameter 450, cutter tower center height 125)
Standard cutting diameter		mm	380
Maximum turning diameter on a skateboard		mm	420
Spindle end type and code			A2-8(optional A2-11)	Spindle unit
Main shaft hole diameter		mm	80
Maximum pass bar diameter		mm	70
Single spindle headstock	Spindle speed range / Maximum spindle output torque	r/min/Nm	50 ~ 3500/215
Main motor Output power	30 minutes/continuo us	kW	18.5/15
Standard chuck	Chuck diameter	inch	10(optional 12)""
X axis fast shift speed		m/min	12
Z-axis fast shift speed		m/min	16
X-axis stroke		mm	250
Z-axis stroke		mm	2050
Standard knife holder form			Horizontal 12 station servo
Tailstock travel		mm	1950

Product Description
1. A high rigidity structure with high precision and stability, and large cutting feed.
2. This machine tool can process shaft and disc parts, turn threads, arcs, cones, and the inner and outer surfaces of rotating bodies, and perform efficient, large-scale, and high-precision processing on rotating body parts.
3. In the design, the stiffness of components such as the spindle, bed, and tailstock is reasonably matched, and the guide rail adopts a fully hard rail form, greatly improving the rigidity of the entire machine and ensuring stability during re cutting.
4. As a universal machine tool, it is particularly suitable for efficient, large-scale, and high-precision processing of rotating parts in industries such as locomotives and aerospace.
Detailed Photos

Machine structure 1.Integrated casting bed body, resistant to tension and earthquake resistance. 2.45 ° inclined bed for more convenient chip removal.

Servo Turret 1. Standard: Horizontal 12''inch servo turret 2. Optional: Live turret

Servo Turret 1. Standard: Horizontal 12''inch servo turret 2. Optional: Live turret

Hard rail tailstock 1. High stability, 2. Strong rigidity 3. Helps improve processing accuracy 4. Increase load capacity 5. Long service life
