China Truck Body Refrigarated Truck Dry Van GRP Floor Sheets Tank Truck Refrigerator Car Dry Van RV Construction Panels

China Truck Body Refrigarated Truck Dry Van GRP Floor Sheets Tank Truck Refrigerator Car Dry Van RV Construction Panels

US$8.00
300-9,999 Square Meters
US$7.60
10,000+ Square Meters

Basic Info.

Thickness
1-3mm
Usage
Industral
Product Categories
FRP Pipe
Molding Method
Resin Transfer Molding
Material
Fiberglass
Fiber Type
GFRP
Type
Diphenyl Ether FRP
Width
2500mm
Length
as Per Clients′ Requests
Transport Package
in Rolls or Crates
Specification
1.2-3.0mm
Trademark
Kaisi
Origin
Yangzhou
HS Code
3921909090
Production Capacity
2000 Square Meters Per Day

Product Description


Applications:sandwich panels, refrigerator car,decorative sheets, truck box body, wagon panels, dry van sheets, container panels, trailer panels, outdoor vacation panels, food processing plants, cold storage, brewing beer plants, pharmaceutical factories, laboratories, hospitals, chemical plants, public bathhouses, toilets, warehouses, supermarkets, pleasure ground, schools, car washing, and yachts . Suitable for versatile indoor applications and without varnishing also for outdoor use. Fiberglass Flat Sheet WS enables a huge selection of FRP sheet in various thickness and widths to a maximum length of 200 linear meters. All FRP sheet can be high gloss, matte, in Ral colors and comes supplied with a removable clear plastic film to protect the outer face. The inside face can be sanded to aid bonding and give a uniform thickness throughout the width of 200 linear meters in any width up to and including 2.5 meters. Main component: polyester resin, well-balanced glass content, gelcoat layer Quality assured by: continuous manufacturing process and constant process control. Data to name a few:
Specifications units Cited Thickness
1.0mm 1.5mm 2.0mm 2.5mm 3.0mm
Weight Kg/m2 1.3 2 2.6 3.2 4.0
Glass content % 19 25 29 30 30
Tensile strength Mpa 60 80 92 95 97
Elongation at break % 1.5 1.5 1.5 1.5 1.5
Elastic modulus Gpa 5.5 7 7.3 7.6 7.8
Izod impact strength KJ/m2 45 55 70 80 95
Please note: that glass sheet is supplied in coils at maximum length of 200 linear meters. However, Depending on quantity required it is possible to order sheet in flat packs cut to size. Yangzhou Wansheng Industry Co., Ltd. is a professional manufacturer of fiberglass sheets, FRP decorative panels, serving building industry and RV industry, commercial trucks and bodies, and equipment facilities, such as Incubators, solar plants, etc. All of these products are exported to the USA,Canada,Australia,the Middle East, Africa etc.
