New Automatic Al Melt Blown Non Woven Fabric Machine High Accuracy
| US$520,000.00 | 1 Sets (MOQ) |
Basic Info.
Model NO.
SMS PP sounbond nonwoven machine
Automatic Grade
Automatic
Certification
CE SGS ISO9001
Condition
New
Raw Material
Polypropylene Chips
Key Selling Points
Long Service Life
After Warranty Service
Video Technical Support, Online Support
Weight
20t
Dimension(L*W*H)
10m*13m*25*
Voltage
220V to 440V
Warranty of Core Components
2 Years
Width
2400mm
Power
250kw
Core Components
PLC, Engine, Bearing, Gearbox, Motor
Applicable Industries
Garment Shops, Building Material Shops
Power Input
350kVA
Machine Type
Al-2400mm Ss
Capacity
4800ton/Year
Final Froducts
Ss Spunbond Nonwoven Fabric
Transport Package
Export Standard Packing
Trademark
AL
Origin
Zhejiang, China
Production Capacity
1 Set/Sets Per Month, 3500t
Product Description
Medical Standard SSS Nonwoven Fabric Making Machine/ Nonwoven Fabric Production LineProduct Description
Three beams nonwoven machine is also short for SSS. Three beams form one web by spun bonding. The spunbond nonwoven is generated by extruding a thermoplastic fiber polymer into fine filaments fiber. The size arranges from fifteen to thirty-five micrometer diameter. The filaments are collected on a conveyer belt in the form of a web. Then it is bonded to make spunbond nonwoven fabric. The nonwoven fabrics possess properties of excellent burst strengths, stability to heat & chemicals, porosity and tear strength.
SSS Nonwoven Fabric Application SSS nonwoven fabrics are commonly used in healthy products such as baby diaper, sanitary napkin, face mask. It's also workable for material of garments and shoes such as clothes interlining and shoe cover.
| Model No. | SSS-1600 | SSS-2400 | SSS-3200 | Custom |
| Machine Size | L31*W13*H10m | L32*W14*H10m | L34*W15*H10m | |
| Machine Speed | 450m/min | 450m/min | 450m/min | |
| Gram Weight | 10-150 GSM | 10-150 GSM | 10-150 GSM | |
| Daily Output | 12 tons | 24 tons | 28 tons | |
| Nonwoven Width | 1600 mm | 2400 mm | 3200 mm |
S Model ( Packagings, Agricultural Cover )
| Working Width | Fabric GSM | Consumption | Annual Output/Year |
| 1600mm | 9-250 | 130KW | 1500T |
| 2400mm | 9-250 | 180KW | 2400T |
| 3200mm | 9-250 | 200KW | 3000T |
| 4200mm | 9-250 | 300KW | 3800T |
SS Model ( Baby Diaper, Medical Products )
| Working Width | Fabric GSM | Consumption | Annual Output/Year |
| 1600mm | 10-250 | 200KW | 3000T |
| 2400mm | 10-250 | 250KW | 4800T |
| 3200mm | 10-250 | 300KW | 6000T |
| 4200mm | 10-250 | 450KW | 7500T |
SMS/SMMS/SSMS/SSMMS Model ( Filtration Material, Baby Diaper, Medical Products )
| Working Width | Fabric GSM | Consumption | Annual Output/Year |
| 1600mm | 15-250 | 400KW | 3500T |
| 2400mm | 15-250 | 600KW | 5000T |
| 3200mm | 15-250 | 800KW | 6500T |
Working Process of PP Spunbond Nonwoven Fabric Making Machine.
Additive (recycling waste )----->Raw material----> Melting and Extruding----->Filtering----> Measuring----> Spinning ----> Cooling-----> Air drawing----->Web forming ----> Calendering---->rolling up----> cutting and packing
Installation Instructions
Company Profile
Certifications
FAQ
FAQ of 2400mm SS Spunbond Nonwoven Fabric Making Machine.
How to visit your factory?
1 hour from Shanghai to our city by fast train.
