8 cbm compressed waste collection garbage compactor refuse truck

Product Description

8 cbm compressed waste collection garbage compactor refuse truck
8m3 FAW garbage truck/ refuse compactor truck/ garbage compactor truck
Product description
3-4 Tons Refuse Truck
Type: HTC5080ZYSC
Cabin: J5K/ TVH/ J6F with A/C
Engine Model: CA6110/ 4DL160
Emission standard: Euro 2
Power (KW): 160/ 180/210HP
Clutch model: 380mm, single plate, dry, diaphragm
Gearbox Model: manual type transmission
Rear Axle: CA435 wheel reduction axle
Rear Axle speed ratio: 5.143.
Wheel & tire: 9/ 10.00-20, Model 16Ply Rating
Axle Base: 3750/ 4300/ 4700mm
Fuel Tank: 200L
Overall dimensions Length: 7695mm
Width: 2500mm
Height: 3100mm
Front overhang(loaded): 1375mm
Rear overhang(loaded): 2720mm
Passing angle(loaded) Approach angle: 19
Departure angle: 13
Parameter Curb weight (kg): 6000
Gross truck weight(kg) 8000 kg
Volume of tank: 6-8 m3
Volume of Sewage Tank: 200 L.
Product parameters

Truck model				CA5120
Manufacturing Company				FAW
Drive wheel				4x2
Engine	Model			CA6110/125Z1A2
	Manufacturing Company			FAW
	Maximum output			170HP
	Emission standard			Euro II
	Number of cylinder			6-cylinder in-line with water cooling, turbo-charging and intercooling
Transmission				CA6TB085M
Clutch				Ф380mm
WABCO valve, WABCO clutch booster, maintenance-free battery
Front Axle				8E
Rear Axle				435 (rate:5.571)
Chassis		Frame		237*75*7mm
		Fuel tank		200L
Steering				Power-assistant, RHD
Brakes				Drum
Wheel Base(mm)				3750
Wheels&Tires				10.00R20-16 tyre
Driver's cabin			Model, description	J5K, Without A/C
			Sleeper	1
			PTO	Yes
Electrics			Operating voltage	24v
			Starter, Alternator	China brand
Overall Dimensions			Overall Length	8148mm
			Overall Width	2436mm
			Overall Heigth	3250mm
Weigth			Gross vehicle weigth	18000kg
			Front axle capacity	6000kg
			Rear axle capacity	11500kg
Performance			Volume of body	6 m3
			Volume of filler	0.8 m3
			One loading cycle	≤25(s)
			Filler lift time	8-10(s)
			One unloading time	≤35(s)
			Seawage tanker(F+R)	50+100
			Max break compressure	16Mpa
			Max. driving speed	70 km/h
