Plastic Conical Double Twin Screw CPVC UPVC PVC Pipe Extruder for 16/50/63/110/160/250/315/400/630/800mm Water Drainage Sewing Sewer Electric Conduit Hose Tube

Product Description

Plastic Conical Double Twin Screw CPVC UPVC PVC Pipe Extruder for 16/50/63/110/160/250/315/400/630/800mm Water Drainage Sewing Sewer Electric Conduit Hose Tube Product Description
· Mixing PVC powder, CACO3 and other addictives.
· Widely used in PVC pipe and profile production. · Composed of high speed mixer (hot mixer), cooling mixer and control cabinet.· Stainless steel SUS304 for the internal wall construction. It will guarantee the mixer could use for long time under the high friction. · The mixing blades are passed the static and dynamic balance testing. And the main shaft adopts fine sealing to prevent material leakage.
Different models for options: SJSZ51/105, SJSZ65/132, SJSZ80/156 and SJSZ92/188.High quality electrical components, like Siemens, Omron, Fuji, Delta, etc.Alloy screw & barrel, which guarantee high quality and stable output.Equipped with high qualty gearbox and distributor.Extruder control by PLC screen touch is available as well; PLC screen touch is from Siemens (customized).
GF series Vacuum calibration Tank, SUS304 with spraying painting or pure SUS304 body is for option.
Available sizes for different pipe diameters from 16mm upto 800mm.
Equipped with famous and high-quality vacuum pump and water pump with overload protection; water temperature auto controlling.
4/6/8/10/12 cooling tubes installed inside of the Tank, with ABS sprayers.
5meters, 6meters, 9meters and other lengths for option, according to different pipe pressure requirements.
For different pipe diameters, we offer the suitable Haul off unit, like Double claw, Four-claw, three claw, four claw, six claw, eight claw, etc.
Machine speed control is with ABB Inverter.
Machine is controlled together with Vacuum calibration Tank and Cutter.
Normal Knife-lifting Cutter and Planetary Cutter are available for small and large pipe diameters.
Both types of cutters are equipped with dust collector.
Product Parameters

Model/Item	GF63	GF110	GF160	GF250	GF400	GF630	GF800
Diameter range/mm	20-63	20-110	50-160	50-250	110-400	315-630	400-800
Extruder model	SJSZ65/132	SJSZ65/132	SJSZ65/132	SJSZ80/156	SJSZ92/188	SJSZ92/188	SJSZ92/188
Driving motor power/kw	37	37	37	55	90	110	132
Pipe pulling speed/meters/minute	12-15	10-12	5-8	4-6	3-4	0.5-2	0.5-1

Detailed Photos

Certifications
Machining Equipment
Package and container loading
More Products For Option
FOR MORE DETAILS, PLS FEEL FREE TO CONTACT US. THANKS!
