Industrial 7 Inch LCD Touch Screem Tij Thermal Inkjet Coding Printer
| US$2,200.00-2,800.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
PM001
Usage
Daily Industrial, Chemical Products, Drug, Food
Automatic Grade
Automatic
Principle of Classification
Thermal Inkjet Technolog
Application of Classification
Ink Jet Printer
Working Patterns
On-Line
Supplies
Ink
Packaging
Cans
Condition
New
Certification
CE Certificate
Control Type
PLC
Weighing Scale
Optional
Brake Motor
Yes
Voltage
220VAC, 50Hz
Printing precision
Vertical: 150Dl, 300DPI, 600DPI / Horizontal: 0-60
Language
English, Arabic, Korean, Italian,Russian, Spanish
Operation System
Embedded Linux Security Operating System
Printing Material
Carton, Metal, Plastic, Pipe, Cable, Board, Glass
Transport Package
Steel Frame + Wooden Box
Specification
L1100-1200*W1000-1100*H1000-1500MM
Origin
China
HS Code
8443393100
Production Capacity
500set/Per Month
Product Description
Industrial 7 Inch LCD Touch Screem Tij Thermal Inkjet Coding PrinterProduct Description
| Instruction | 7.0-inch color industrial-grade large touch screen, information editing function is more simple to operate, the print speed per minute 120 m/300 DPI, 60 m/600 DPI, industrial standard stainless steel body, stronger anti-interference ability, higher level of protection, support for 20 kinds of multi-language, the nozzle separation design is more convenient. |
| Printhead type | TIJ2.5 Thermal Foam Nozzle |
| Printing precision | Vertical: 150Dl, 300DPI, 600DPI / Horizontal: 0-600DPI |
| Printing height | Minimum printing 1mm, single printhead printing height 12.7mm |
| Printing distance | Optimum print distance 1-2mm |
| Printing material | Corrugated carton |
| Ink type | Water-based, solvent 42ml cartridge |
| Ink Color | Black color |
| Cartridge Chip | RFID contactless chip tag, automatic identification of ink parameters and recording of ink balance |
| Operating System | Embedded Linux operating system |
| Main Hardware | U.S. TIAM3358 industrial-grade CPU, U.S. Xilinx Spartan6 industrial-grade FPGA, TIJ with ASIC chip |
| Machine Communication Interface | Network interface, USB, RS232 |
| External Interface | Photoeye, synchronizer, flip upside down control, alarm output, serial number output, external serial number reset, external serial number update, external print information selection, printhead connection 1-2 |
| Supported Languages | Multi-language (Chinese/English/Arabic) |
| Power Supply Parameters | 100-240V converter output 30V4A DC output |
| Material | Industrial standard stainless steel |
| Machine Specifications | 202mm*119m*61mm (actual subject to production) |
| Working Environment | Temperature 0-45°C/Humidity 30-70%Rh |
| Note | Ink cartridges are printing consumables, no warranty |
| Product Color | Subject to production |
FAQ Q1.How about product packaging?
A:Before the product is shipped, it will bepacked Plywood box plus bottom tray(wooden tray or steel tray).
Q2. What is your terms of delivery?
A: EXW, FOB, CIF...
Q3.How about your payment term? What kind of payment term you can accept?
A:As usual, the payment term is TT,30% deposit, the balance after machine testing and before delivery.
Q4. How about your delivery time?
A: Generally, it will take 15-20 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5.How to answer technical guidance?
A:We will provide solutions based on theirspecific requirements, combined withtechnical feasibility and production costs.
Q6.How about the product transportation?
A:Products are generally shipped fromShenzhen Port, China to the destination portby sea.
