Flexible Magnetic Strip for Fridge Door

Product Description

Flexible Magnetic Strip for Fridge Door Product Description Our rubber magnetic strip is available in thickness from. 030" (0.762mm) to 120"(3.05mm) and width of 1/2"(12.7mm) to 3"(76.2mm) The strip magnetized in a multipole arrangement for a strong pull on only one side, or in a conventional through-the-thickness arrangement that provides an equally strong pull on both sides. Our magnetic strip is shipped in coils, and can be cut or scored to meet individual requirements. The strip is available either plain or with pressure sensitive adhesive...
Features:
1. Specifications: 9 x 3mm, 8 x 2mm, 9 x 2.5mm and more
2. Property: Isotropic or anisotropic fridge strip...
3. Magnetizing: Multi-pole on one side, mark on unmagnetized surface
4. Application: Apply to fridge, freezers and disinfectors door strip.

Product Parameters

Item	Specification	Shape on un-magnetizing side	Magnetizing direction	Hardness /A	Property Attraction weight/g
YXFS-1	8± 0.15× 2± 0.1	three grooves	N-S-N	≥ 97	50~62
YXFS-2	9± 0.15× 2± 0.1			≥ 97	54~66
YXFS-3	10.8± 0.1× 2.5± 0.07	a groove	S-N-S	≥ 96	≥ 95
YXFS-4	9.2± 0.15× 2.2(1.8)± 0.1	a linear mark		≥ 97	71~85
YXFS-5	9± 0.15× 2.7± 0.07	a groove	S-N-S	≥ 96	≥ 82
YXFS-6	11± 0.1× 2.1± 0.05			≥ 96	≥ 85
YXFS-7	11.3± 0.1× 2.9± 0.05	two linear marks	N-S-N	≥ 96	≥ 100
YXFS-8	9.1± 0.1× 2.1± 0.05			≥ 97	≥ 75
YXFS-9	10± 0.15× 3± 0.07		N-S-N	≥ 96	≥ 96
YXFS-10	10+0.15-0.1× 3+0.05-0.1	a groove		≥ 96	≥ 96
YXFS-11	9± 0.15× 3± 0.07	two linear marks	N-S-N	≥ 96	≥ 96

Detailed Photos
After Sales Service For more detail info, please feel free to visit our website or inquire us at any of your convenience.
