Waterproof Water Filled Inflatable Rubber Dam Air Inflatable Rubber Weir
Product Description
Product DescriptionProduct Description
Details Images
Feature
Water retaining: By inflating the airbag, it supports the water shield shield to achieve water storage.
Water supply: When the water storage height exceeds the height of the water shield, the water flows through the shield, and the
airbag and support system are protected by the shield under the shield without receiving damage.
Dam height adjustment: Adjust the height and angle of the water shield by adjusting the air volume to control the height of the
water surface.
Drainage: By venting the air in the airbag, the water shield and airbag can lie at the bottom of the riverbed, and the support
Specification
| Dam model number | Design of high dam | internal pressure ratio | Dam Radial calculated strength | Dam perimeter of section | Dam length | Dam thicikness | safety factor |
| LY-1.0 | 1.0 | 1.00 | 5.00 kn/m | 3.48m | 0.60m | 8mm | 36.00 |
| LY-1.5 | 1.5 | 1.00 | 11.28 kn/m | 5.23m | 0.90m | 8mm | 20.00 |
| LY-2.0 | 2.0 | 1.00 | 20.00 kn/m | 6.97m | 1.20m | 10mm | 13.50 |
| LY-2.5 | 2.5 | 1.00 | 31.26 kn/m | 8.71 m | 1.51m | 10mm | 11.52 |
| LY-3.0 | 3.0 | 0.90 | 40.6 kn/m | 10.57m | 1.93m | 12mm | 11.12 |
| LY-3.5 | 3.5 | 0.80 | 49.00 kn/m | 12.58 m | 2.41m | 12mm | 10.10 |
| LY-4 | 4 | 0.80 | 64.00 kn/m | 14.36 m | 2.77m | 14mm | 12.65 |
