SCITEK Unique Neck Design Liquid Nitrogen Filling Tank With Rollers
| US$990.00-1,700.00 | 1 unit (MOQ) |
Basic Info.
Model NO.
LNC-100-40
Condition
New
Customized
Customized
Certification
ISO9001, CE
Tank Marerial
Metal Tank
Type
Low Temperature Storage & Transportation Equipment
Storage Objects
Bio Samples That Need Long-Term Static Storage
Ln2 Capacity (L)
100
Neck Opening (mm)
40
Overall Height (mm)
1185
Outer Diameter (mm)
606
Weight Empty (Kg)
75
Transport Package
Wooden Package
Specification
100 L
Trademark
SCITEK
Origin
China
HS Code
7309000000
Production Capacity
100 Units/Months
Packaging & Delivery
Package Size
71.00cm * 71.00cm * 141.00cm
Package Gross Weight
95.000kg
Product Description
Product DescriptionLiquid Nitrogen Tank Features: Unique neck design, low evaporation loss rate.
With rollers for easy to move.
Level display is optional.
Regulator is optional for stable pressure.
Solenoid valve is optional.
Reliability:
A protective operating ring.
Safe structure.
Stainless steel tank.
Five years vacuum warranty;
The stainless steel structure design is suitable for most environment and reduces the rate of evaporation losses.
Liquid nitrogen tank mainly applicable to laboratory users and chemical users for liquid nitrogen storage and liquid nitrogen automatic supply.
Product Parameters
| Model | LNC-100-40 | LNC-150-40 | LNC-200-40 | LNC-240-40 | LNC-300-40 | LNC-500-40 |
| Performance | ||||||
| LN2 Capacity (L) | 100 | 150 | 200 | 240 | 300 | 500 |
| Neck Opening (mm) | 40 | 40 | 40 | 40 | 40 | 40 |
| Daily Evaporation Rate Of Static Liquid Nitrogen (%) | 1.3 | 1.3 | 1.2 | 1.2 | 1.1 | 1.1 |
| Transfusion Volume (L/min) | / | / | / | / | / | / |
| Maximum Storage Capacity | ||||||
| Overall Height (mm) | 1185 | 1188 | 1265 | 1350 | 1459 | 1576 |
| Outer Diameter (mm) | 606 | 706 | 758 | 758 | 857 | 1008 |
| Weight Empty (kg) | 75 | 102 | 130 | 148 | 202 | 255 |
| Standard Working Pressure (mPa) | 0.05 | |||||
| Maximum Working Pressure (mPa) | 0.09 | |||||
| Setting Pressure Of The First Safety Valve (mPa) | 0.099 | |||||
| Setting Pressure Of The Second Safety Valve (mPa) | 0.15 | |||||
| Pressure Gauge Indication Range (mPa) | 0~0.25 | |||||
| Gross Weight (kg) | 95.43 | 129 | 161.43 | 174 | 229.5 | 321 |
| Shipping Size(WxDxH) (mm) | 710x710x1410 | 810x810x1400 | 860x860x1450 | 860x860x1530 | 960x960x1640 | 1120x1120x1770 |
| Model | LNC-5-40 | LNC-15-40 | LNC-30-40 | LNC-50-40 |
| Performance | ||||
| LN2 Capacity (L) | 5 | 15 | 30 | 50 |
| Neck Opening (mm) | 40 | 40 | 40 | 40 |
| Daily Evaporation Rate Of Static Liquid Nitrogen (%) | 3 | 2.5 | 2.5 | 2 |
| Transfusion Volume (L/min) | / | / | / | / |
| Maximum Storage Capacity | ||||
| Overall Height (mm) | 510 | 750 | 879 | 991 |
| Outer Diameter (mm) | 329 | 404 | 454 | 506 |
| Weight Empty (kg) | 15 | 23 | 32 | 54 |
| Standard Working Pressure (mPa) | 0.05 | |||
| Maximum Working Pressure (mPa) | 0.09 | |||
| Setting Pressure of the First Safety Valve (mPa) | 0.099 | |||
| Setting Pressure of the Second Safety Valve (mPa) | 0.15 | |||
| Pressure Gauge Indication Range (mPa) | 0~0.25 | |||
| Gross Weight (kg) | 25.88 | 31.86 | 44.81 | 60.74 |
| Shipping Size(WxDxH) (mm) | 390x390x785 | 490x490x935 | 500x500x1080 | 605x605x1250 |
