Large Format Laser Plotter for PCB Industry with High Resolution
| US$30,000.00-40,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
BC
Type
External Drum Imagesetters
Automatic Grade
Automatic
Scan Mode
Drum Scanning
Recording Resolution
DPI
Performance Parameters
Repeat Accuracy
Film Size
762*660mm
Scan Resolution
8000-24000dpi
Precision
0.01mm
Operation Mode
Automatic
Size
1120*920*1170
Transport Package
Wooden Cases
Specification
1800
Trademark
DB
Origin
China
HS Code
8442309000
Production Capacity
100sets/Year
Product Description
Technical parameter| Model | BC-4600 | ||||
| Film size | 660×508mm | ||||
| Laser channels | 650nm LD, 64 channels | ||||
| Scanning resolution | 8000DPI | 12000DPI | 16000DPI | 20000DPI | 24000DPI |
| Min.line space/line width | 1.5mil (0.04mm) | 1mil (0.025mm) | 0.7mil (0.018mm) | 0.55mil (0.014mm) | 0.4mil (0.01mm) |
| Scanning time (Max.film size) | 3min10sec | 4min40sec | 8min30sec | 12min- 50sec | 18min- 40sec |
| Scanning mode | External drum | ||||
| Repeatability precision | ±0.01mm | ||||
| Plate loading & unloading mode | Full automatic film loading & unloading, with online film processor | ||||
| Max.cassette capacity | 15-20 (with dark room) | ||||
| Machien size(LxWxH) | 1120mm×910mm×1150mm | ||||
| Model | BC-2630 | ||||
| Film size | 762×660mm/762×610mm/660×508mm | ||||
| Laser channels | 650nm LD, 64 channels | ||||
| Scanning resolution | 8000DPI | 12000DPI | 16000DPI | 20000DPI | 24000DPI |
| Min.line space/line width | 1.5mil (0.04mm) | 1mil (0.025mm) | 0.7mil (0.018mm) | 0.55mil (0.014mm) | 0.4mil (0.01mm) |
| Scanning time (Max.film size) | 4min40sec | 7min | 12min20sec | 19min- 25sec | 27min- 40sec |
| Scanning mode | External drum | ||||
| Repeatability precision | ±0.01mm | ||||
| Plate loading & unloading mode | Full automatic film loading & unloading, with online film processor | ||||
| Max.cassette capacity | 15-20 sheets (with dark room) | ||||
| Machien size (LxWxH) | 1120mm×920mm×1150mm | ||||
| Weight | Around 500KG | ||||
Machine picture
