Non-Woven Fabrics Point Breaking Shearing Rewinding Machine

Product Description

Non-woven fabrics point breaking shearing rewinding machine
Raw material specification 1200-2500*1200 mm (30-120 g water washed non-woven fabrics)
Raw material roll core 76 mm
Slitting width 100 mm, equipped with pressign cutting shearing device
Winding diameter 1200 mm can produce both big rolls or small rolls
Full servo tension control synchronous feeding or magnetic powder control
One set unfolding material frame equipped with one 74 air shaft roller
Automatic correcting error device
Equipped with a rolling type rubber roller used for unfolding cloth wrinkle
Driving unit equipped with one set of steel to rubber roller
Perforation device adopting screw blade to perforate dotted line with pitch adjustable. Equipped with servo electrical machine or chain transmission to control length of pitch
Equipped with pneumatic pressing rolelr at rolling part, used for adjusting folding degree of thighness (optional)
Speed 0-120 m/min
Motor 3-3.5 kw
Rewinding unit adopts servo or variable frequency motor synchronous rolling
Automatic counting with both pitch number counting or meter counting
Rolling paper core 76 and 38 mm (to be ordered)

Our service:
⇒One year guarantee for whole machine, all life follow-up service.
⇒24 hours technical support by email.
⇒Technicians overseas set-up and workers training.
⇒User- friendly English for operation system.
Packing and delivery
Packaging Details:Film+ honeycomb board packing.
Delivery Detail:Shipped in 90 days after payment.
THE PACKING IS SEAWORTHY AND SAFE.
Exhibitions:


Q1: What is the warranty for the machine?
A1: For the machine,we offer one year warranty.If any quality problems occurred under normal condition during this period ,we will take on the costs of maintenance and replacement and other related cost.
Q2: How to operate and maintain the machine?
A2: First, we will provide a professional and detailed manual to you with the machine; Second, we will test and debug the machine into the best condition before shipment for you . Last but not least, we also provide abroad technical training service and online expertise consulting.
Q3: How to get raw material or auxiliary material for the machine?
A3: Our company has over10 years experience in this industry, we have accumulated various contact information of upstream&downstream firms in fields of raw material,auxiliary material and package for the products. We believe that our professional team can always offer you the best solutions.
Q4: How to find the matching accessories or wearing parts of the machine?
A4: We offer free replacement for wearing parts during the warranty period. Clients can also get the parts from us with favorable price if it is out of the warranty.
