Manual Type Saddle Move Surface Grinding Machine M7125 250X500

Product Description

Surface Grinding Machine M7125-2
Manual type surface grinding machine M7125 worktable size 250x500

Description			M7125
G rinding Capacity: LX W XH		mm	500X250X330
Longitudinal table travel		mm	520
Cross table travel		mm	270
Max. Distance from the spindle centre to the worktable surface		mm	430
S afety load of bench ( in max )		kg	100
T able size		mm	500 X 250
T-slot		mmXn	12 X 1
B ench speed		m/min	3-23
Cross auto feed		mm	-
Cross rapid feed		mm	-
C ross handwheel	Per graduation	mm	0.0 2
	per revolution	mm	3
Grinding W heel size( DXWXd)		mm	200X16X31.75/32
S pindle Speed		R/min	2850
Max.. Movement of the vertical mechanism		mm	430
V ertical fine adjustment revolution		mm	1
V ertical per fine adjustment graduation		mm	0.005
S pindle moter		kw	1.1
O verall dimensions: (LXWXH)		mm	1260X1190X1660
Packing size(LXWXH)		mm	1300X1220X1950
G/N weight		T	1.2 / 1.1

1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as surface grinding machine, CNC surface grinder ,CNC Milling Machine ,Vertical Machining Center ,Drilling Machine ,gantry milling machine , CNC gantry milling machine, CNC gantry grinding machine so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in NO 370 Changjiang North Road, NANTONG ,JIANGSU ,CHINA. If you have interest to visit our factory, pls inform
me ahead, i will arrange and company you your visit period.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
6: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
We want to know:
1.What's your Industrial Voltage?
2.We strongly suggest you to tell us size, material of your workpiece for our evaluation, if possible, better to send us workpiece drawing, so that we can recommend you most suitable model!
3.If need CIF Price, please kindly tell us the port of destination.
