US$16,000.00-25,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Model NO.
Q1313 Q1319 Q1322 Q1325 Q1327
Processing Accessory
Metal
Guide Rail
Horizontal Guide Rail
Tool Holder
4 Way Tool Post
Controlling Mode
Artificial
Certification
CE, RoHS, ISO 9001
Transport Package
Plywood Case
Production Capacity
10 PCS/Month
Product Description
Product Application
Q13 series pipe threading lathe mainly undertakes the special lathe for pipe thread turning processing. In addition, it can also undertake the turning outer circle, boring, plane and other work of ordinary lathe. It is used in the processing and repair of drill pipe in petroleum, metallurgy, chemical, hydroelectric geology and other departments. , 10,000 drill rods, sleeves, etc.
INDEX | UNIT | Q1325 |
Max swing diameter over bed | mm | 800 |
Max swing diameter over cross slide | mm | 540 |
Max work piece length | mm | 1500 |
Width of bed | mm | 550 |
Spindle bore | mm | 255 |
Power of spindle motor | kw | 11 |
Spinlde speed | r/min | 20-340 VF2 steps |
Z axis feed grade/ range | mm/r | 26/0.07-1.33 |
X axis feed grade/ range | mm/r | 22/0.02-0.45 |
Carriage rapid traverse speed | mm/min | 4000 |
Cross slide rapid traverse speed | mm/min | 1300 |
Metric thread grade/range | mm | 24/1-14 |
Inch thread grade/range | T.P.I | 40/2-28 |
Module thread grade/range | mm | 53/0.2-120 |
DP thread grade/range | D.P | 24/1-28 |
Traverse of cross slide | mm | 430 |
Max traverse of turret | mm | 200 |
Tailstock quill travel | mm | 200 |
Tailstock quill diameter | mm | 100 |
Tailstock quill taper | | MT5 |
Chuck | | Ø630mm 4 jaw manual chuck |
Overall dimensions | mm | 3700x1600x1400 |
Net weight | kg | 6000 |
