US$2,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Application Area
Metallurgy&Mineral
Control System
Button or PLC Control
Mixer Type
Double Screw Cone Mixer
Operating Type
Continuous Operating
Transport Package
Nude Package
Specification
CE ISO9001 ISO14001
Production Capacity
500 Sets Per Month
Product Description
JS500 Double Horizontal Shaft Compulsory Mixer Welcome to the future of construction with our Heavy-Duty Concrete Mixer. This state-of-the-art machine is designed to meet the demands of modern construction projects, offering a blend of power, efficiency, and reliability. Whether you're working on a small residential development or a large commercial project, our mixer is up to the task. Our mixer is not just a tool; it's a partner in your construction journey. With its robust construction and high-capacity drum, it ensures that you have a consistent supply of high-quality concrete, reducing downtime and increasing productivity.
Technical Features
-Features:
1.Equipped with multiple shaft end seal protection devices and wind pressure seal protection devices to effectively prevent leakage;
2.Unique mixer monitoring system can monitor the working status of the reduction box, discharge pump, and electric lubricating oil pump at any time;
3. Equipped with a pressurized upper cover water discharge system, the spraying area is larger and the water discharge is more uniform
4. Equipped with a DC24V centralized lubricating oil pump for concrete mixers, the running time can be programmed independently, it is waterproof, dustproof and has excellent performance;
5. Equipped with an enhanced reduction gearbox, and processed with high-precision technology, it has strong load capacity and longer service life;
Equipped with high-quality high-wear-resistant alloy stirring arms, the service life is 3-5 times that of ordinary stirring arms;
-Applications:
:lt is more suitable for mixing medium & large aggregate particle size. Technical Parameters
Type | LJB350 | JS500 | JS750 | JS1000 |
Charging Volume(L) | 560 | 800 | 1200 | 1500 |
Discharging Volume(L) | 350 | 500 | 750 | 1000 |
Productivity(m³/h) | ≥17.5 | ≥25 | ≥37.5 | ≥50 |
Max. Grain Size of Aggregate(mm) | 60 | 60 | 60 | 60 |
Speed of Mixing Blade(r/min) | 35 | 35 | 32.6 | 32.6 |
Mixing Blade(PCS) | 3 | 14 | 14 | 16 |
Model of Mixing Motor | Y112m-4 | Y180m-4 | Y200L-4 | XWDY9-17-185-6P |
Power of Mixing Motor(KW) | 5.5 | 18.5 | 30 | 18.5x2 |
Model of Winch | JS350 | JS500 | JS750 | JS1000 |
Power of Winch(KW) | 4.5 | 5.5 | 7.5 | 11 |
Height of Unloading Material(mm) | 1200 | 1500 | 1600 | 2080 |
Model of Water Pump Motor | 252B21-0.37 | 252B27-0.75 | 65JDB-30 | KQW65-100 |
Power of Water Pump Motor | 370w | 750w | 1.1KW | 1.5KW |
Frame Dimension in Working Condition(mm) | 3618×1222×3453 | 4461×3050×5225 | 4950×3636×6530 | 7922×3510×6064 |
Transporting Frame Dimension(mm) | 1721×1222×2450 | 3050×2300×2500 | 4150×3636×2500 | 4200×3110×2780 |
Net Weight(T) | 2 | 4 | 6.8 | 9 |
