I Series New Refrigerant Vacuum Pump
| US$20.00-1,050.00 | 10 Pieces (MOQ) |
Basic Info.
Model NO.
I-Series
Origin
China
HS Code
841869
Production Capacity
100000 Sets Per Year
Product Description
Product Parameters| Model | YK-i220SV | YK-i240SV | YK--i260SV | YK-i280SV | YK-i120SV | YK-i140SV | YK-i160SV | YK-i180SV | |
| Power Supply | 220V~/50Hz | 220V~/50Hz | 220V~/50Hz | 220V~/50Hz | 220V~/50Hz | 220V~/50Hz | 220V~/50Hz | 220V~/50Hz | |
| Flow Rate | 50Hz | 1.8 CFM 51 L/min | 3.5 CFM 100 L/min | 5.0 CFM 142 L/min | 7.0 CFM 198 L/min | 1.8 CFM 51 L/min | 3.5 CFM 100 L/min | 5.0 CFM 142 L/min | 7.0 CFM 198 L/min |
| 60Hz | 2.0 CFM 57 L/min | 4.0 CFM 113 L/min | 6.0 CFM 170 L/min | 8.0 CFM 226 L/min | 2.0 CFM 57 L/min | 4.0 CFM 113 L/min | 6.0 CFM 170 L/min | 8.0 CFM 226 L/min | |
| Ultimate Vacuum | Partial Pressure | 2x10-1Pa | 2x10-1Pa | 2x10-1Pa | 2x10-1Pa | 2pa | 2pa | 2pa | 2pa |
| Total Pressure | 15 micron | 15 micron | 15 micron | 15 micron | 15 micron | 15 micron | 15 micron | 15 micron | |
| Power | 1/3 HP | 1/2 HP | 3/4 HP | 1 HP | 1/4 HP | 1/3 HP | 1/2 HP | 3/4 HP | |
| Inlet Port | 1/4" SAE | 1/4" SAE | 1/4" SAE | 1/4" SAE | 1/4" SAE | 1/4" SAE | 1/4" SAE | 1/4" SAE | |
| Oil Capacity | 200 ml | 325 ml | 580 ml | 500 ml | 250 ml | 250 ml | 660 ml | 660 ml | |
| Dimensions (mm) | 318x124x265 | 338x138x275 | 395x145x318 | 395x145x318 | 290x124x255 | 318x124x265 | 338x138x275 | 395x145x318 | |
| Weight | 9 kg | 11 kg | 16.6 kg | 17kg | 6.7kg | 8.6kg | 10.3kg | 15.4kg | |
Operating
Detailed Photos
