Affordable Industrial CNC Machining Center for Superior Performance
| US$24,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
ZXX - C3018
Application
Glass Cabinet Table, Glass Sinks, Shower Door ..., Glass
Process Usage
CNC Non-Conventional Machine Tools
Movement Method
Linear Control
Control Method
Semi-Closed Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01mm, 0.05-0.1(mm)
Performance Classification
High-End CNC Machine Tools
Certification
CE, CE, ISO
Condition
New
Structure
Horizontal
Control System
PLC
Type
Glass Process Center
Glass Washing Machine Type
Waterjet
Glass Edging Machine Type
Drilling, Milling Edging Polishing Together
Grinding Head Number
2
Drawing
CAD Drawing
Heads Number
2
Max.Motion Range
2700*1650mm
Power
13kw
Glass Thickness
3-25mm
Speed
0-20m/Min
Volt.
380V/50Hz ( Can Be as Per Request)
Min Process Size
75X15mm
Fuction
Drilling Milling Grinding Polishin Engraving
Delivery
25days
After-Service
Provides 24 Hours Online Services
Certificate
CE
Trade Mark
Znxu
Transport Package
Standard Export Package
Specification
2300*3300*2200MM
Trademark
znxu
Origin
China
HS Code
8464901900
Production Capacity
50 Sets Per Month
Product Description
| Description | unit | parameter |
| Model No. | 1 | ZXX - C3018 |
| Colum | Set | Heavy iron |
| Control System | set | LEETRO |
| Axis | PC | Cutter change : by hand |
| Diam:ยข125 | ||
| coller:cool water | ||
| RPM:24000 | ||
| POWER:7.5KW | ||
| Drive | set | YMPC |
| Invertor | kw | BEST : 11KW |
| Max glass size put | mm | 3000*1800mm (Length can be no limited by adding table) |
| Max Grinding Size | mm | 2500*1450mm |
| Max router (milling) size | mm | 2700*1650mm |
| Z-axis space height-open | mm | 380 |
| motor | set | CHINT |
| Internal of machine structure | set | Half cover/ waterproof design |
| Work table load weight | KG | 120 |
| Positioning accuracy | mm | 0.01 |
| Repeated positioning accuracy | MM | 0.01 |
| Max speed (empty) | M/MIN | 15 |
| Max process speed | M/MIN | 3M/MIN |
| Stroke protection | PC | Omron,Japan |
| GEAR | PC | GERMAN DMJ-1.5M High precision |
| Guide Screw bearing | PC | HIWIN |
| Model: Z axis with diagonal contact | ||
| Lubrication system | set | Origin : TAIRUN |
| Lubrication automatically | ||
| Cooling type | set | Water pump |
| Main axis cooling | set | Automatic thermostat cooler |
| Main electric | set | CHINT / SCHNEIDER |
| Volt./Frequecny | KW | AC/380v/10KW/50HZ (AS PER CUSTOMER REQUEST) |
| Machine Size | mm | 2250*4000*2200mm |
| weight | KG | 2200 |
| power | KW.H | 11.1 |
