Multi-Row Tooth PDC Drill Bit for Enhanced Cutting and Impact Resistance

Multi-Row Tooth PDC Drill Bit for Enhanced Cutting and Impact Resistance

US$500.00-2,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
IADC 127
Certification
GB/T 19001-2016/Is0 9001:2015
Bit Size (in)
8-1/2"
Bit Size (mm)
215.9
Connection Buckle Type
4-1/2" API Reg
Tooth Type
Steel Teeth
Sealing Type
Rubber Seal
Recommended Rpm (R/Min)
60-180
Recommended Wob (kN/mm)
0.35-0.85
Net Weight (Kg)
38
Gross Weight (Kg)
40
Overall Dimension (mm)
255X255X405
Transport Package
Wooden Box
Specification
215.9 mm
Trademark
TANK
Origin
China

Product Description


Design Features of PDc Oil Drill Bits
1, Blade Design
The design of the blade widens the flow channel of the dril bit, effectively prevents mud clogging, and the asymmetrical blade layout reduces the wear of cutting teeth.
2,Gauge Protection Design
he design of spiral gauge protection surfaces improves tooth density, reduces the effective gauge length of the dril bit,increases the base of the qauge protection surface, and reduces the torgue of the drilbit, This extends the lifespan of thedrill bit and improves its control over water holes.
3,Raised Blade Design
This design provides the drill bit with a stronger attack driling speed, bringing users a more efficient drilling experience.
4,Multi-row Tooth structure Design
This design maintains efficient cutting ability while reducing the risk of wear and damage to the drill bit, effectively improving the stability and impact resistance of the drill bit.
5,Anti-Rotation Design
We have adopted an anti-rotation design to enhance the stability of the blade and increase the driling speed.
SPECIFICATION
IADC code IADC127 Recommended RPM (r/min) 60-180
Bit size (in) 8-1/2" Recommended WOB (KN/mm) 0.35-0.85
Bit size (mm) 215.9 Net weight (kg) 38
Connection buckle type 4-1/2" API REG Gross weight (kg) 40
Tooth type Steel teeth Overall dimension (mm) 255x255x405
Sealing type Rubber seal
FORMATIONS
Soft formations with low compressive strength and high drillability, Such as mudstone, chalk, sat rock, soft limestone, etc.
Sizes of PDC Oil Bits
size API Reg Pin Make-Up Torque(KN.m)
in mm in (KN.m)
4-5/8" 117.5mm 2-7/8 REG 6.1-7.5
6" 152.4mm 3-1/2 REG 9.5-12.2
6-1/2" 165.1mm
6-3/4" 171.5"
7-1/2" 190.5mm 4-1/2 REG 16.3-21.7
7-7/8" 200.0mm
8-1/2" 215.9mm
8-5/8" 219.1mm
8-3/4" 222.3mm
9-1/2" 241.3mm 6-5/8 REG 38-43.4
10-1/2" 266.7mm
12-1/4" 311.2mm
12-1/2" 317.5mm
13-1/2" 342.9mm
13-5/8" 346.1mm
14-3/4" 374.7mm 7-5/8 REG 46.1-54.2
15" 381.0mm
15-1/2" 393.7mm
16" 406.4mm
17-1/2" 444.5mm
26" 660.4mm

Packing-shipping
Company Profile
Shenzhen TANK Drilling Technology & Equipment Co., Ltd. Shenzhen TANK Drilling Technology & Equipment Co., Ltd. specializes in the research, development, production, and sales of PDC mining drill bits, PDC CBM drill bits, PDC oil drill bits, PDC directional drill bits, and a variety of other related products. We are dedicated to delivering high-quality, high-performance drilling products and professional solutions for the global oil, gas, and geological exploration industries. TANK's PDC drill bits demonstrate exceptional wear resistance, impact resilience, and cutting efficiency across diverse geological formations. With advanced materials and manufacturing techniques, we ensure the stability and reliability of our drill bits, enabling efficient drilling operations even in complex geological conditions. We also provide professional technical support to our clients, including assistance in drill bit selection, to enhance their productivity and minimize costs. TANK boasts a research and development team comprising senior engineers and technical experts who have extensive industry experience and profound professional knowledge. They are constantly dedicated to the innovation of new products and the improvement of existing ones. With a modern production facility,advanced manufacturing equipment, and a perfect quality management system, we ensure the consistency and reliability of our products. Furthermore, our professional customer service team use their extensive industry knowledge and service experience to provide timely and efficient pre-sale, in-sale, and after-sales services to our clients. TANK relentlessly pursues technological innovation and is committed to developing new materials and advanced manufacturing processes to further enhance the performance and durability of PDC drill bits. Our products have gained a strong presence in both domestic and international markets and are widely used in the oil, gas, geological exploration, and other related industries. We have established long-term and stable partnerships with numerous enterprises worldwide and have earned widespread acclaim and trust from our customers. Continuing adhere to technological innovation, TANK will strive to continuously improve our product quality and service standards. We are dedicated to providing our clients with superior PDC drill bit products and solutions, contributing to promote the development of global oil, gas and geological exploration industries. FAQ Q1. Can I have a sample order?
Answer:Yes, we welcome sample order to test. Mixed samples are acceptable. Q2. If you accept customized according to customers' requirements? Answer: Yes, we accept customized, no matter what size and type, and MOQ is 1 piece. And we also provide OEM service. You can provide your design, and we sign CA with each other. Q3. Are you original manufacturer or trading company?
Answer: We are an integrated corporation specialized in manufacturing and exporting. Q4. What is your main products? Answer: Our main products including PDC Directional Bits, PDC Mining Drill Bits, PDC Oil Drill Bits, Tricone bits, PDC Cutters, Down the Hole Bits, Drill Rod, DTH Hammer and Shield Cutter. Q5. What type of drill bit should I be using? Answer: When asking that question there are a lot of variables: the formation you are drilling in; the size of hole your drilling; the size pump you have; if you are drilling with mud or air; and the size of your rig. Call us on our 24 hour phone number or write us an email, we will help you make the right bit choice. Q6. Do you provide after-sales service? Answer: Timely after-sale assistance shall be provided all the time. Free change once the problem caused by the quality issue. Q7. What is the production capacity of your factory ? Answer: Our production capacity is about 6,000 to 10,000 bits per month. Q8. What is your delivery time? Answer: 3-7 days for frequent ordered models&size which we always hold stocks. 15-30 days for newly produced goods and customization products. Q9. What payment methods do you support? Answer: We accept all regular payment terms including L/C, T/T, Western Union, X-Transfer, etc. Q10. What are the shipping methods? Answer: Express: DHL, TNT, UPS, FedEx and Special lines… Carrier: by air or sea. They all apply to a very economic cost.
