Lty-6000 Smart Servo Plastic Injection Molding Technology for Efficiency
| US$20,000.00 | 1 SET (MOQ) |
Basic Info.
Model NO.
LTY-6000
Type
Plastic Product Injection
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008, GMP, QS
Transport Package
Wrap Film Packing Into The Container
Specification
580T
Trademark
LOYALTY
Origin
China
HS Code
8477101090
Production Capacity
1000sets/Years
Product Description
| SPECIFICATION | LTY6000 | ||||
| A | B | C | D | ||
| INJECTION UNIT | |||||
| SCREW DIAMETER | mm | 90 | 95 | 100 | 105 |
| SCREW L/D RATIO | L/D | 20 | 19 | 18 | 17.1 |
| SHOT VOLUME(THEORETICAL) | cm3 | 2544 | 2835 | 3140 | 3461 |
| INJECTION WEIGHT(PS) | g | 2315 | 2580 | 2858 | 3149 |
| INJECTION RATE | g/s | 552 | 612 | 679 | 748 |
| INJECTION PRESSURE | MPa | 184 | 165 | 149 | 135 |
| SCREW SPEED | rpm | 150 | |||
| CLAMPING UNIT | |||||
| CLAMP FORCE | KN | 6000 | |||
| OPEN STROKE | mm | 850 | |||
| SPACE BETWEEN TIE BARS(W*H) | mm | 870x870 | |||
| MAX.MOULD HEIGHT | mm | 900 | |||
| MIN.MOULD HEIGHT | mm | 350 | |||
| EJECTOR STROKE | mm | 250 | |||
| EJECTOR FORCE | KN | 150 | |||
| OTHER | |||||
| MAX.PUMP PRESSURE | MPa | 16 | |||
| PUMP MOTOR POWER | kW | 30+37 | |||
| HEATING POWER | kW | 42.95 | |||
| MACHINE DIMENSION(L*W*H) | m | 10.3x2.22x2.61 | |||
| OILTANK CUBAGE | L | 900 | |||
| MACHINE WEIGHT | t | 28 | |||
