Multi channel M70 portable paperless recorder,Portable data acquisition systems
Product Details
Product Details
Product Description
Product DescriptionHide embedded handles for protable applications, Easy to pull and easy to carry.
FTP server function optional
Modbus RTU / Modbus TCP communication protocol for realtime data transfer.
Folding door cover,Not only equipment but also industrial art
Independent power switch design, free to use
7-inch color touch screen,Let the work status at a glance,Human-computer interaction interface is concise and friendly
USB Interface - Mass Storage
Support multiple sample frequency for long time information collection, 0.1s to 24h...
Import data into a USB flash drive by setting the time period
Support statistical analysis of data
Powerful PC software for data analysis, save and so on... View and analyze, 7-inch color touch screen
AC85-265V/DC24V extra supply power for sensors optional,
USB interface to easily export data, Embedded installation 278*278 hole
Isolated universal input, multiple signal acquisition
Embedded handles are easy to carry for protable applications
Acquisition Module Specifications：
| Input type | Measurement range | Measurement accuracy | display resolution | |
| Measuring range | ±10V | -11.000V to +11.000V | ±0.05%of rdg±2 digit | 1mV |
| ±5V | -5.500V to +5.500V | ±0.05%of rdg±2 digit | 1mV | |
| ±100mV | -110.0mV to +110.0mV | ±0.05%of rdg±2 digit | 0.01mV | |
| 0-20mA | 0 to +20.00mA | ±0.05%of rdg±2 digit | 0.01mA | |
| 4-20mA | 4 to +21.00mA | ±0.05%of rdg±2 digit | 0.01mA | |
| K | -100℃ to +1372℃ | ±0.05%of rdg±0.6℃ | 0.05℃ | |
| J | -100℃ to +1200℃ | ±0.05%of rdg±0.6℃ | 0.05℃ | |
| E | -100℃ to +1000℃ | ±0.05%of rdg±0.6℃ | 0.05℃ | |
| T | -100℃ to +400℃ | ±0.05%of rdg±0.5℃ | 0.01℃ | |
| N | -100℃ to +1300℃ | ±0.05%of rdg±0.6℃ | 0.05℃ | |
| w | 0℃ to +1500℃ +1500℃ to +2315℃ | ±0.05%of rdg±0.8℃ ±0.05%of rdg±1.1℃ | 0.05℃ 0.05℃ | |
| R | 0℃ to +300℃ +300℃ to +1768℃ | ±0.05%of rdg±1.6℃ ±0.05%of rdg±0.9℃ | 0.05℃ 0.05℃ | |
| S | 0℃ to +300℃ +300℃ to +1768℃ | ±0.05%of rdg±1.6℃ ±0.05%of rdg±0.8℃ | 0.05℃ 0.05℃ | |
| B | +400℃ to +600℃ +600℃ to +1820℃ | ±0.05%of rdg±1.7℃ ±0.05%of rdg±1.0℃ | 0.05℃ 0.05℃ | |
| pt100 | -200℃ to +600℃ | ±0.1%of rdg±0.3℃ | 0.02℃ | |
| cu50 | -50℃ to +150℃ | ±0.1%of rdg±0.3℃ | 0.02℃ |
