Ultra-High Efficiency 60Hz 50Hz, Ie3 Series Three-Phase AC Asynchronous Induction Electric Motor

Product Description

Product Description TYCP series three-phase permanent magnet synchronous motor mounting size is completely consistent with Y and Y2 seriesmotors. Customers can directly purchase TYCP series synchronous motors to replace Y and Y2 series asynchronous motors.
Permanent magnet motors have the following advantages: 1. High power factor. 2. High starting torque. 3. Good performance indicators. 4. The efficiency and power factor of permanent magnet synchronous motors decrease very little. When the motor has only 20% load, its force energy index is still above 80% of full load. 5. When the Y series motor operates at 60% load, the efficiency decreases by 15%, the power factor decreases by 30%, and the force and energy index decreases by 40%; However, the efficiency and power factor of permanent magnet synchronous motors decrease very little. When the motor has only 20% load, its force energy index is still above 80% of full load. 6. Low temperature rise: There is no resistance loss in the rotor winding and almost no reactive current in the stator winding, resulting in low motor temperature rise. 7. Small size, light weight, and low consumables: The volume, weight, and materials used for permanent magnet synchronous motors of the same capacity can be reduced by about 30%. 8. Capable of atmospheric gap formation, facilitating the formation of new magnetic circuits. 9. The armature has a small reaction and strong overload resistance. Product Parameters

Model	Output power (KW)	Speed (R/min)	Frequency (HZ)	Rated torque (N.m)	Rated current (A)	Eff (%)	Rate voltage (V)	Weight (KGS)
	TYCP series standard speed 3000R/min
TYCP90S-2.2-30	2.2	3000	150	7	4	88	380	22
TYCP90l-3-30	3	3000	150	9.6	5.4	89.1	380	25
TYCP90l-4-30	4	3000	200	12.7	7.3	90	380	32
TYCP100l-5.5-30	5.5	3000	200	17.5	10	90.9	380	39
TYCP100l-7.5-30	7.5	3000	200	23.9	13.6	91.7	380	46
TYCP132S-11-30	11	3000	200	35	20	92.6	380	55
TYCP132S-15-30	15	3000	200	47.8	27.2	93.3	380	61
TYCP132m-18.5-30	18.5	3000	200	58.9	33.6	93.7	380	88
TYCP160m-22-30	22	3000	200	70	39.9	94	380	108
TYCP160m-30-30	30	3000	200	95.5	54.5	94.5	380	158
TYCP180m-37-30	37	3000	200	117.8	67.2	94.8	380	168
TYCP180m-45-30	45	3000	200	143.3	81.7	95	380	180
TYCP225S-55-30	55	3000	200	175.1	99.8	95.3	380	298
TYCP225S-75-30	75	3000	200	238.8	136.1	95.6	380	320
TYCP225m-90-30	90	3000	200	286.5	163.4	95.8	380	377
TYCP250m-110-30	110	3000	200	350.2	199.7	96	380	401
TYCP250m-132-30	132	3000	200	420.2	239.6	96.2	380	480
TYCP280s-160-30	160	3000	200	509.3	290.4	96.3	380	515
TYCP280m-200-30	200	3000	200	636.7	363	96.5	380	570

Model	Output power (KW)	Speed (R/min)	Frequency (HZ)	Rated torque (N.m)	Rated current (A)	Eff (%)	Rate voltage (V)	Weight (KGS)
	TYCP series standard speed 1500R/min
TYCP90S-1.5-15	1.5	1500	75	9.6	2.7	88.2	380	21
TYCP90l-2.2-15	2.2	1500	75	14	4	89.5	380	25
TYCP100l-3-15	3	1500	75	19.1	5.4	90.4	380	29
TYCP100l-4-15	4	1500	100	25.5	7.3	91.1	380	36
TYCP112m-5.5-15	5.5	1500	100	35	10	91.9	380	42
TYCP132m-7.5-15	7.5	1500	100	47.8	13.6	92.6	380	58
TYCP132m-11-15	11	1500	100	70	20	93.3	380	63
TYCP160l-15-15	15	1500	100	95.5	26.8	93.9	380	114
TYCP160l-18.5-15	18.5	1500	100	117.8	33	94.2	380	122
TYCP180m-22-15	22	1500	100	140.1	39.3	94.5	380	165
TYCP180l-30-15	30	1500	100	191	53.6	94.9	380	190
TYCP225S-37-15	37	1500	100	235.6	66.1	95.2	380	290
TYCP225l-45-15	45	1500	100	286.6	80.4	95.4	380	325
TYCP225l-55-15	55	1500	100	350.2	98.3	95.7	380	367
TYCP250m-75-15	75	1500	100	477.5	134	96	380	440
TYCP250m-90-15	90	1500	100	573	160.8	96.1	380	525
TYCP250m-110-15	110	1500	100	700.3	196.5	96.3	380	550
TYCP280m-132-15	132	1500	100	840.4	235.8	96.4	380	608
TYCP280m-160-15	160	1500	100	1018.7	285.8	96.6	380	670

Model	Output power (KW)	Speed (R/min)	Frequency (HZ)	Rated torque (N.m)	Rated current (A)	Eff (%)	Rate voltage (V)	Weight (KGS)
	TYCP series standard speed 3000R/min
TYCP90l-1.1-10	1.1	1000	50	10.5	2	84.5	380	25
TYCP90l-1.5-10	1.5	1000	50	14.3	2.7	85.9	380	27
TYCP100l-2.2-10	2.2	1000	50	21	4	87.4	380	29
TYCP112m-3-10	3	1000	66.7	28.7	5.4	88.6	380	41
TYCP132m-4-10	4	1000	66.7	38.2	7.3	89.5	380	43
TYCP132m-5.5-10	5.5	1000	66.7	52.5	10	90.5	380	45
TYCP160l-7.5-10	7.5	1000	66.7	71.6	13.6	91.3	380	99
TYCP160l-11-10	11	1000	66.7	105.1	20	92.3	380	108
TYCP180m-15-10	15	1000	66.7	143.3	27.2	92.9	380	180
TYCP180m-18.5-10	18.5	1000	66.7	176.7	33.6	93.4	380	187
TYCP225s-22-10	22	1000	66.7	210.1	39.9	93.7	380	298
TYCP225m-30-10	30	1000	66.7	286.5	54.5	94.2	380	305
TYCP225m-37-10	37	1000	66.7	353.4	67.2	94.5	380	315
TYCP250m-45-10	45	1000	66.7	429.8	81.7	94.8	380	379
TYCP250m-55-10	55	1000	66.7	525.3	99.8	95.1	380	387
TYCP280s-75-10	75	1000	66.7	716.3	136.1	95.4	380	520
