Grinder Gear Carbide Insert Grinding Machine-Automatic CNC Double/Two Head Milling Machine

Grinder Gear Carbide Insert Grinding Machine-Automatic CNC Double/Two Head Milling Machine

US$75,000.00
1-5 set
US$68,888.00
6+ set

Basic Info.

Model NO.
LC-1530MO
Abrasives
Grinding Wheel
Controlling Mode
CNC
Automatic Grade
Automatic
Cylindrical Grinder Type
Universal Cylindrical Grinder
Precision
High Precision
Certification
GS, CE, RoHS, ISO 9001, SGS
Condition
New
Cutting with
2000*1000mm
Transport Package
Volumn Package &Wooden Package
Trademark
LC Machine
Origin
Dongguan
HS Code
8460241900
Production Capacity
5000 Pieces/Year

Product Description

LC-1530MO CNC GANTRY GRINDING MACHINE
Product Introduction

The grinder adopts enclosed frame structure with sufficient rigidity and durability of guide rail. The horizontal feed and vertical feed of grinding head are driven by servo motor with ball screw to ensure high feed precision and improve operation convenience. Using humanized operation control panel, convenient operation and measurement, ensure the accuracy of machine tool.
Base Data

Main Technician Parameters
Item Description Unit Specification
System Control mode PLC

Work range
X axis mm 3000
Y axis mm 1500
Z axis mm 750
Inner Width mm 1900
Worktable Worktable area mm 3000×1500
Max. Loading kg 8000
T-groove (number - size * spacing) mm 22*180-5
Electric permanent magnet disk mm 3000×1500

Grinder
Motor Power KW 18.5
Grinding wheel specifications / Φ500*75*203
Revolution rpm 1200
Main specifications mm Φ170
Speed X/Y/Z axis feeding speed mm/min 3000/500/500

others
floor area mm 9500×3800
weight kg 23000
max. height of machine mm 3500

Main Configuration List
Seq Item Specification Quantity Producer
1 base plate Φ100*25
2 set bolt M20-400
3 tool kit Wrenches, screwdrivers, etc 1piece
4 grinding wheel 500*75*203 1 set
5 ring flange 1 set
6 balancer 1piece
7 user manual 1 set E-File
8 ground plot 1 set E-File

Manufacturing

Production Capacity

Factory Address: No.1 Yintai North Road, Shutian, Humen Town, Dongguan, City, China
R&D Capacity: Own Brand, ODM, OEM
No. of R&D Staff: 160
No. of Production Lines: Above 10
Annual Output Value: US$15Million
APPLICATION


Company Profile Launch Precision Machinery Co.,Ltd (LC Machine) is a professional modern enterprise, with long-term research & development, manufacturing, sales, after-service. The company gathered engineer team who engaged in CNC machine and mould manufacturing for decades , won trust and support from domestic and oversea clients by good idea, excellent design,reliable quality,full service.
The company has absorbed the advantages of NC technology from Germany and Japan and gathering the leading technology from domestic and foreign industries. All machines are marked ISO 9001 and CE, exported to 58 countries. Main products: Duplex milling machine, Vertical gantry milling machine, Side milling machine, Powerful gantry grinder, Cutting machine, Chamfering machine etc.
We are committed to be the No.1 brand in 6 side milling machine and one-stop service supplier in mould processing industry, serving global client , promoting mould processing industry to reach new level.


After-Sale Service
1. Installation services for free.
2. Operation training for free.
3. We will create files for every client, to track product quality and after service.
4. Providing one year (12 months) warranty for free except for the wrong operation by the user . The spare part is not on the free warranty list.
5. Providing maintenance and repair service termly.
6. Seller will provide solution way within 72 hrs once receiving A-F service request from the buyer.

FAQ
Q: Are you a manufacturer or Trading Company?
A: We are a innovative interprise with rich import & export experience and 10 professional production line.Warmly welcome you to visit our factory. Q: Do you have Agency in my country?
A: With the development of our company, we are expanding export gradually to get a bigger worldwide share of marketing.(The United States/ Korea / India / Southeast Asia etc.). Till now, we have agence in India/Korea/Thailand/ Vietnam, please feel free to contact us to get more detail.
Q: How can I Install the machine, and What should I do if my machine was broken down
A: We provide free installation service to your home. If your machine was broken, please contact us immediately and we will give you solution way within 48 hours.
Q: Can you support OEM Service?
A: Sure, As your requirement, We would like to make the plan and provide the best service for you.
